Broadcom Multirate Low-Power 10-GbE RZ/NRZ/Duo-Binary Transceiver with 10G Clock - BCM8155
Fully integrated MSA-compatible multirate SONET/SDH/10-GbE/Fibre-Channel/FEC transceiver operating at 8.5 Gb/s, 9.1 Gb/s, 9.953 Gb/s, 10.3125 Gb/s, 10.519 Gb/s, 10.664 Gb/s, 10.709 Gb/s, 11.095 Gb/s, 11.318 Gb/s or 11.352 Gb/s.
It supports RZ, NRZ and duo-binary modulation formats. On-chip clock synthesis is performed by a high-frequency, low-jitter PLL, allowing the use of a low-frequency reference clock selectable to the line rate divided by 16 or 64. The 10G TX clock phase adjusts for clocked driver applications.
Features
- Fully integrated multirate CDR, DEMUX, MUX, CMU
- 300-pin Multisource Agreement (MSA) compatible
- Enhanced capability for long-haul transmission with the ability to enable RZ modulation on the transmitter
- Compliant with OIF, Telcordia, ITU-T, XFI specification and IEEE 802.3ae standards
