The Cisco C-SM-16P4M2X and C-SM-40P8M2X service modules are layer-2 Switch modules that provide enhanced security, reliability, and performance. The Cisco C-SM-16P4M2X and C-SM-40P8M2X modules provide Small Form-Factor Pluggable (SFP) /Small Form-Factor Pluggable Plus (SFP+), 1 Gigabit, 2.5 mGiG, and 10G connectivity to the Cisco Catalyst 8300 Series Edge platforms. They also, provide 10G-capable internal uplink to central forwarding data plane on modular ISR platforms.
The Cisco C-SM-16P4M2X and C-SM-40P8M2X service modules are capable of supporting standard Power over Ethernet (PoE), Power over Ethernet Plus (POE+), Cisco Enhanced Power over Ethernet (EPoE), and Cisco Universal Power over Ethernet (UPoE) on all copper ports. A maximum of 60 watts of power for each copper port is supported by leveraging both signal and spare pairs.
This article describes how to install the C-SM-16P4M2X and C-SM-40P8M2X module in the Cisco Catalyst 8300 Series Edge platforms. This installation includes the installation of Small-Form-Factor pluggable (SFP) modules. It also describes how to connect the service module in your network.
Limitations of Cisco C-SM-16P4M2X or C-SM-40P8M2X Service Modules
The limitations of the C-SM-16P4M2X and C-SM-40P8M2X service modules are:
-
Either the C-SM-16P4M2X or the C-SM-40P8M2X service module is supported within a single chassis.
Cisco NIM-ES2-4/NIM-ES2-8 and C-SM-16P4M2X cannot co-exist within a single chassis due to feature incompatibility. When you Switch between legacy and next-generation Switching modes, you need to reload the system.
- After installing the service module, you must reload the system to enable and activate the new next-generation Switching feature set.
- Gigabit Ethernet Ethernet technology for a reliable, convenient way of communication and connectivity
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Service Module offers enhanced dependability with maximum productivity
- Service Module with optical network application/usage for maximum productivity and usability
