Combine four HDMI 2.0 signal connections to one device, build a highdefinition visual world with 4K@60Hz HDCP 2.2 HDR 10 & ARC and equipment audio extraction & embedded.
HIGH QUALITY HDMI SWITCHER: Connect and switch between four HDMI 2.0 sources and display on one HDMI display with 4K@60Hz / HDCP 2.2 / HDR 10, ARC, and audio extraction
BROAD COMPATIBILITY: Fully supports many HDMI devices such as Cable box, Roku, Apple TV, Blu-ray player, Nintendo Switch, Xbox One X, PS4 Pro, Android TV box and other HDMI sources
RICH AUDIO FEATURES: Advanced audio extraction allows audio extraction through Optical TOSLINK SPDIF (2PCM/Digital 5.1) or RCA/AUX (2 PCM) stereo audio
LATEST HDMI TECHNOLOGY: HDR10 (High Dynamic Range 10) capable of brighter whites and deeper blacks from any 4K HDR supported source device, ARC (Audio Return Channel) will easily return you sound from display side to device's Toslink output.
Connectors:
4x 19-pin, HDMI, Female, Input
1x 19-pin, HDMI, Female, Output
1x Switch button
1x ARC button
1x EDID button
1x Audio In button
10x Source and Audio LED
1x IR Receiver
1x Power LED
1x Micro-USB
1x AUX Audio, Input
1x SPDIF, Input
1x SPDIF, Output
1x RCA, Output
1x Power Jack
Power Adapter:
Input: 100-240V AC / 50-60Hz, 0.2A MAX
Output: DC 5V/1A
UL listed: E305498 / Level: VI
Environmental conditions:
Operating temperature: 23 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: 5% to 90% RH (non-condensing)
