ASRock Motherboard WRX90 WS EVO - Supports AMD Ryzen Threadripper PRO 7000 and AMD Ryzen Threadripper 7000 Series Processors

The cooling is also strong with several aluminum fins attached to massive heat pipes which are responsible for cooling the 18+3+3 Phase (105A) VRMs. The motherboard is made up of a server-class 12-layer PCB design and the motherboard features 3 8-pin ATX connectors, 2 8-pin ATX 12V, and 2 6-pin ATX 12V connectors. All of these connectors are required to be plugged in for CPU & memory overclocking.

• Supports AMD Ryzen Threadripper PRO 7000 and AMD Ryzen Threadripper 7000 Series Processors
• 18+3+3 Power Phase Design, 110A SPS Design
• Supports 4 DIMMs DDR5 ECC Registered memory
• 3 PCIe 5.0 x16, 2 PCIe 4.0 x16
• Realtek ALC1220 7.1 CH HD Audio, Nahimic Audio
• 4 SATA3,
  1 Blazing M.2 (PCIe Gen5 x4),
  1 Hyper M.2 (PCIe Gen4 x4),
  1 MCIO (PCIe Gen5 x4),
  2 SlimSAS (PCIe Gen4 x4 / 4 SATA3)
• 1 USB 3.2 Gen2x2 Type-C (Rear),
  2 USB 3.2 Gen2 Type-C (1 Rear, 1 Front),
  4 USB 3.2 Gen2 Type-A (Rear),
  4 USB 3.2 Gen1 (2 Rear, 2 Front),
  4 USB 2.0 (Front)
• Marvell 10 GbE LAN,
  Realtek 2.5 Gigabit LAN
• 802.11ax WiFi 6E + Bluetooth

Ultimate Performance & Rock-Solid Stability

To ensure stability for AMD Ryzen Threadripper 7000 and AMD Ryzen Threadripper PRO 7000 WX-Series processors in all conditions and systems loads, the WRX90 WS EVO & TRX50 WS have been given a flagship-class server grade ultra-low loss PCB and 18+3+3 phase SPS Dr.MOS VRM design to ensure ultimate performance and superb reliability, even when subjected to the most demanding sustained workloads.

To deliver ultimate performance and longevity, both motherboards are equipped with super large aluminum heat-pipe-designed heatsink with server-grade cooling fans, providing ultimate heat dissipation, especially under overclocking.

Extreme Storage & PCIE 5.0 Performance

The new processor provides a monstrous amount of PCIe 5.0 lanes and PCIe 4.0 lanes, with 144 usable PCIe 5.0/4.0 lanes for the WRX90 and 88 PCIe usable 5.0/4.0 for the TRX50, both motherboards are equipped with ample amounts of PCIe slots for expansion, PCIe 5.0 x4 ‘Blazing' M.2 NVMe SSD Sockets, SlimSAS(SFF-8654) and MCIO connector offering the latest high speed and stable storage expansion possibilities, providing numerous storage options making them the perfect choice for your next high-end desktop or even workstation build.

Ultimate Network Connectivity

Fast large file transferring is crucial for content creators, therefore TRX50 WS is equipped with Marvell10 GbE & Realtek 2.5 GbE LAN to ensure superfast file-transfer speed to local server, NAS, or Cloud storage. The wireless network is also available on both motherboards, Wi-Fi 6E with a 2x2 antenna improves connection reliability and provides gigabit-class wireless networking, giving the convenience of high-speed, wire-free connectivity.
