AsRock Rack Server Barebone 2u2e-gnr2/2t Dual Socket E2 (lga 4710), Intel Xeon 6700e-series Dual 10gbe - Gigabit Ethernet - Power Supply - Rj45, Dedicated Ipmi, Type-a (usb 3.2 Gen1), Db15 (vga) - 2U2E-GNR2/2T
Specifications
| System | |
| Form Factor | 2U Rackmount |
| Dimensions | 580 x 438 x 87 mm (22.8'' x 17.2'' x 3.4'') |
| Support MB | GNR2D16-2T |
| Front Panel | |
| Buttons | Power button w/ LED, ID button w/ LED, System reset |
| LEDs | HDD Activity, LAN 1/2, System Event |
| I/O Ports | 2 Type-A (USB3.2 Gen1) |
| External Drive Bay / Storage | |
| Front Side Drive Bay | 2 Hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays |
| Internal Side | 2 M-key (PCIe5.0 x2), supports 22110/2280 form factor [CPU0] |
| Power Supply | |
| Type | 1+1 CRPS |
| Output Watts | 1000W @100-127Vac input / 1600W @200-240Vac input |
| Efficiency | 80-PLUS Platinum |
| AC Input | Low-line: 100-127Vac, 60/50Hz; High-line: 200-240Vac, 60/50Hz |
| System Fan | |
| Fan | 4 Hot-swap 80x56 mm fans, 1 fixed 40x28 mm fan |
| Processor System | |
| CPU | Supports Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors |
| Socket | 1+1 Socket E2 (LGA 4710) |
| Thermal Design Power | Up to 350W |
| Chipset | System on Chip |
| System Memory | |
| Supported DIMM Quantity | 8+8 DIMM slots (1DPC) |
| Supported Type | DDR5 RDIMM |
| Max. Capacity per DIMM | RDIMM: 128GB |
| Max. DIMM Frequency | RDIMM: 6400MT/s |
| PCIe Expansion Slots (SLOT7 close to CPU) | |
| PCIe x 16 | Rear: 5 HHHL single-slot PCIe5.0 x16 |
| PCIe x 8 | Rear: 1 HHHL single-slot PCIe5.0 x8 |
| TPM | |
| TPM support | 1 (13-pin, SPI) |
| Ethernet | |
| Additional GbE Controller | 2 RJ45 (10GbE) by Intel® X710-AT2 |
| Server Management | |
| BMC Controller | ASPEED AST2600: IPMI2.0 with iKVM and vMedia support |
| IPMI Dedicated GLAN | 1 Realtek RTL8211F for dedicated management GLAN |
| Rear I/O | |
| UID Button/LED | 1 UID button w/ LED |
| Video Port | 1 DB15 (VGA) |
| Serial Port | 1 DB9 (COM) |
| USB 3.2 Gen1 Port | 2 Type-A (UBS3.2 Gen1) |
| RJ45 | 2 RJ45 (10GbE), 1 dedicated IPMI |
| System BIOS | |
| BIOS Type | AMI UEFI BIOS; 512Mb SPI Flash ROM |
| BIOS Features | Plug and Play, ACPI 4.0 and above compliance wake up events, SMBIOS 3.4 and above, ASRock Rack instant flash |
| Hardware Monitor | |
| Temperature | CPU, MB, Card side Temperature Sensing |
| Fan | Fan Tachometer CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Fan Multi-Speed Control |
| Voltage | PSU +12V & +5VSB & +3.3V, +3VSB, PVNN_PCH, P1V05_PCH_STBY, P1V8_PCH_STBY, +BAT, PVCCIN_CPU0, PVCCIN_CPU1, PVCCINFAON_CPU0, PVCCINFAON_CPU1, PVCCFA_EHV_FIVRA_CPU0, PVCCFA_EHV_FIVRA_CPU1, PVCCD_HV_CPU0, PVCCD_HV_CPU1 |
| Environment | |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
| Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
