Broadcom 28nm Octal 25G/28G Unidirectional Repeater - BCM82109
The BCM82109 is footprint-compatible with the BCM82209 and available in an 8mm x 13mm, 135-pin BGA, RoHS-compliant package.
Features
- Eight channels 25G/28G unidirectional repeater/equalizer
- Multiple standard/data rate support from 10G to 28G
- Low-power 28nm design, <100 mW per channel
- High performance programmable signal conditioning, including up to 16 dB in RX CTLE and up to 6dB in TX de-emphasis
- Auto negotiation and link training protocol pass-through between link partners
- MDC/MDIO host interface
- Broadcom Serial Control (BSC) host interface
- Integrated AC-coupling capacitors on all high speed receivers
- Reference-less
- 8mm x 13mm BGA package, 0.8 mm ball pitch
- Footprint compatible with the BCM82209 Lite PHY
Applications
- Line Cards
- Repeaters
- Top-of-Rack Switches
