Broadcom Dual-Channel 10-GbE SFI-to-XAUI LAN/WAN PHY with 1588 - BCM84728
Dual-channel 10-Gigabit Ethernet (GbE) SFI-to-XAUI LAN/WAN PHY that incorporates an electronic dispersion compensation (EDC) equalizer supporting SFP+ line card applications.
The BCM84728 is a lower-power version of the BCM8728 dual SFI-to-XAUI PHY and also supports 1588 and WAN interface Sublayer (WIS) mode. The BCM84728 is a multirate physical layer device targeted for SMF, multimode fiber (MMF) or copper twin-ax applications interfacing to both limiting-based and linear-based SFP+ and SFP modules. The BCM84728 is fully compliant with the 10GbE IEEE 802.3aq standard and also supports 1000BASE-X and SGMII modes.
Features
- Dual-channel SFI-to-XAUI transceiver
- Supports SFP+ SR, LR and LRM optical interfaces
- SFF-8431 CX1 compliant
- LRM mode supports 300m of MMF, exceeding the IEEE 802.3aq standard
Applications
- Enterprise LAN Switching
- DSLAMs
- Blade Servers
- Line Cards
- Routers
- Top-of-Rack Switches
