Broadcom Quad-port 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX Ethernet CMOS transceiver - BCM84888
The Broadcom BCM84888 is a quad-port 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX Ethernet CMOS transceiver.
BCM84888 is a highly integrated solution that supports USXGMII, XFI, 5000BASE-X, 2500BASE-X, and 1000BASE-X (SGMII) MAC interface
The BCM84888 features the Energy Efficient Ethernet (EEE) protocol. EEE enables the BCM84888 to auto-negotiate and operate with EEE-compliant link partners to reduce overall system power during low utilization of the link. Broadcom’s AutogrEEEn mode permits legacy systems to enjoy the power saving benefits of EEE.
The BCM84888 features Enhanced Cable Diagnostics, which detects common cable problems such as shorts, opens, and cable length.
Features
- Single-chip integrated quad-port Ethernet transceiver-MAC to magnetics:
- 10GBASE-T IEEE 802.3an
- 5GBASE-T 802.3bz
- 2.5GBASE-T 802.3bz
- 1000BASE-T IEEE 802.3ab
- 100BASE-TX IEEE 802.3u
- 5G NBASE-T spec.
- 2.5G NBASE-T spec.
- XFI/10GBASE-KR, USXGMII, 5000BASE-X, 2500BASE-X, and 1000BASE-X (SGMII) MAC Interfaces
- 5G rate over USXGMII/XFI/5000BASE-X MAC interfaces
- 2.5G rate over USXGMII/XFI/2500BASE-X MAC interfaces
- IEEE 1588-2008 PTP version 2 (Time Stamp)
- EEE on 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, and 100BASE-TX
- Low electromagnetic interference (EMI) emissions
- Enhanced cable diagnostics
- Support for jumbo packets up to 18 KB
- Low-power, 1.0V CMOS core
- Device package: 19 mm × 19 mm BGA
Applications
- Ethernet switches and uplinks
- Ethernet server
- Broadband CPE
