The Crestron® HD-MD6X2-4K-E is a simple to use, ultra high-definition signal switcher with six HDMI® inputs and two HDMI outputs. It handles Full HD 1080p, Ultra HD, 2K, and 4K video signals with support for HDCP, 3D, Deep Color, and high-bitrate 7.1 audio. Operation is enabled using the front panel controls, a Web browser, or a Crestron control system. Simplified setup is facilitated through the front panel OLED display or a Web browser.
4K Ultra HD
4K video support provided by the HD-MD6X2-4K-E is essential for use with the latest generation of UHD and 4K DCI displays and sources, as well as computers and monitors with native resolutions beyond 1080p and WUXGA.
QuickSwitch HD® Technology
Digital media signals are typically encrypted to protect against unauthorized viewing. After authenticating displays or signal processors, a source device must issue a key before delivering an output signal. Crestron QuickSwitch HD technology manages these keys to ensure fast, reliable switching and immunity to display blackouts caused by key authentication.
NOTE: QuickSwitch HD technology requires the use of a scaling HDMI output which is available on DigitalMedia devices such as the DM-RMC-4KZ-SCALER-C and DMC-4KZ-HDO.
EDID Format Management
To ensure that every source gets displayed at its optimal resolution and format, the HD-MD6X2-4K-E provides comprehensive management of EDID (Extended Display Identification Data) information. For applications requiring custom configuration, the HD-MD6X2-4K-E allows for easy assessment of each device's format and resolution capabilities with the ability to configure signals appropriately.
1RU Rack-Mountable
The HD-MD6X2-4K-E can be placed on a shelf, or mounted in a 19 in. EIA equipment rack using the rack ears provided. When rack-mounted, it occupies a single rack space. The front panel label strips can be customized using Crestron Engraver software or standard 3/8 in. tape labels, allowing for the clear designation of each input and output. Inputs and outputs may also be designated by name to appear on the OLED display.
