CyberPower OL3000RTXL2U Smart App Online UPS Systems - 3000VA/2700W, 100 - 125 VAC, NEMA L5-30P, 2U, Rack / Tower, Sine Wave, 7 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty PURESINE LCD L5-30P 100-125V RT 3YR
Prevent business interruptions and safeguard mission-critical enterprise network equipment.
The CyberPower OL3000RTXL2U is a rack/tower UPS with double conversion topology. It provides sine wave output to critical applications and equipment that require seamless power correction. The Extended Battery Module (EBM) expands runtime, and Fast Charge Technology restores full backup power faster. This model comes with an extendable LCD control panel, Smart Battery Management charging technology, and energy-saving GreenPower UPS™ ECO Mode.
The OL3000RTXL2U offers generator compatibility and delivers clean AC power with zero transfer time. Its sine wave output keeps sensitive equipment working by preventing unnecessary shutdowns that can occur with simulated sine wave output.
With a $400,000 lifetime connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to high quality.
Features
- Capacity: 3000 VA / 2700 W
- Power Factor (PF): 0.9
- Topology: Double-Conversion
- Waveform: Sine Wave
- Output: 100, 110, 115, 120, 125 V ±2% (configurable)
- Plug type & cord: NEMA L5-30P, 10 ft. cord
- Outlet types: 6 × NEMA 5-20R, 1 L5-30R
- Monitoring & Management: USB, Serial, Network, Relay, EPO
- Data line surge protection: Telephone, Network
- Management software: PowerPanel® Business Edition
Controls/Indicators
| Status Indicators | LED Indicators: - Power On (White)
- Line Mode (Green)
- Battery Mode (Yellow)
- Bypass Mode (Yellow)
- Fault (Red)
- Replace Battery (Red)
|
Management
| Network Management | SNMP/HTTP Remote Monitoring |
| Alarm | Battery Mode |
Warranty
| Limited Warranty | 3 Year |
| Directly Connected Equipment Guarantee | $400000Lifetime |
| $400000Lifetime |
Environmental Conditions
| Thermal Dissipation | 327.07 W |
| Maximum Operating Temperature | 104°F (40°C) |
| Maximum Operating Elevation | 10000 ft |
| Maximum Storage Elevation | 50000 ft |
Interfaces/Ports
| Network (RJ-45) | Yes |
| Modem (RJ-11) | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
Physical Characteristics
| Weight (Approximate) | 68.20 lb |
| Color | Black |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Height | 3.5" |
| Width | 17" |
| Depth | 23.6" |
General Information
| Product Type | Dual Conversion Online UPS |
| Manufacturer Part Number | OL3000RTXL2U |
| Manufacturer Website Address | http://www.cyberpowersystems.com |
| Manufacturer | CyberPower Systems, Inc |
| Product Model | OL3000RTXL2U |
| Product Name | Smart App Online OL3000RTXL2U 3000VA 100-125V Sine Wave LCD Rack/Tower UPS |
| Product Series | Smart App Online UPS |
| Brand Name | CyberPower |
Miscellaneous
| Additional Information | - Replacement Battery Cartridge Quantity: 1
- Smart Battery Management (SBM) Mode: Yes
- Circuit Breaker: 30A
- Cold Start: Yes
- Input Plug Type: NEMA L5-30P
- Input Power Factor: 0.99
- Crest Factor: 3:1
- Harmonic Distortion: < 3% at Linear Load
- On Battery Frequency: 50/60 Hz ± 0.25Hz (auto-sensing or configurable)
- Overload Protection: Line Mode: 105% ~ 125% Load - 1 min
- VA by Input Type: 3,000 (3.0 kVA) at 120, 125 V input
- Watts by Input Type: 2,700 (2.7 kW) at 120, 125 V input
- Phone / Network Protection RJ11/RJ45: 1-In / 1-Out (Combo)
- Dry Contacts: Yes
- Expansion Slot: Yes - with optional RMCARD305 or RELAYIO500
- LCD: Multifunction LCD
- LED Indicators: Power On (White)
- Management Cable: USB Cable
- Removable LCD Control Panel Option: Yes - Requires DB26 cable (not included)
- Rotatable LCD Control Panel Option: Yes
- Material of Construction: Metal
- Mounting Hardware: Yes
- ECO Mode Thermal Dissipation: 465 BTU/hr
- Operating Relative Humidity: 0 - 90 % (non-condensing)
- Operating Temperature: 32 - 104 °F (0 - 40 °C)
- Storage Relative Humidity: 0 - 95% (non-condensing)
|
| Package Contents | - Smart App Online OL3000RTXL2U 3000VA 100-125V Sine Wave LCD Rack/Tower UPS
- PowerPanel Business Edition Software CD
- User Manual
- USB Cable
- Serial Cable
- Phone Cable
- Mounting Hardware
- Registration Card
|
| Software Included | PowerPanel® Business |
| Certifications & Standards | UL1778 |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
| Energy Star | No |
Battery Information
| Battery Chemistry | Sealed Lead Acid (SLA) |
| Battery Size | 12V |
| Battery Capacity | 9000 mAh |
| Number of Batteries | 6 |
| Backup/Run Time (Half Load) | 11 Minute |
| Backup/Run Time (Full Load) | 3.50 Minute |
| Battery Characteristics | Maintenance-free |
| Replaceable Battery | Yes |
| Typical Battery Recharge Time | 4 Hour |
Power Description
| Input Voltage | 120 V AC |
| Output Voltage | 110 V AC |
| 115 V AC |
| 125 V AC |
| 120 V AC |
| 100 V AC |
| Surge Energy Rating | 1335 J |
| Waveform Type | Sine Wave |
| Input Voltage Range | 60 V AC - 69 V AC |
| 60 V AC - 69 V AC |
| Output Frequency | 60 Hz |
| 60 Hz |
| Input Frequency | 70 Hz |
| 70 Hz |
Technical Information
| Application/Usage | Mission Critical Equipment |
| Dataline Protection | RJ-11 |
| RJ-45 |
| Overload Protection | Yes |
| Protection Type | Surge |
| Plug/Connector Type | NEMA L5-30P |
| Receptacle Type | NEMA 5-20R |
| NEMA L5-30R |
| EMI/RFI Noise Filter | Yes |
| Energy Saving | ECO Mode Efficiency >95% |
| Number of Battery & Surge Outlets | 7 |
| Transfer Time | 0 ns |
| Receptacle Detail | 6 x NEMA 5-20R |
| 1 x NEMA L5-30R |
