Dataram 4GB DDR3 SDRAM Memory Module - 4 GB - DDR3-1600/PC3-12800 DDR3 SDRAM - 1600 MHz - CL11 - 1.35 V - Non-ECC - Unbuffered - 204-pin - SoDIMM - Lifetime Warranty DDR3 1600MHZ SODIMM CL11 1.35V
DVM16S2L8/4G is a non-ECC Unbuffered 512Mx64 small -outline memory module, which conforms to JEDEC's DDR3L-12800, PC3-1600 standard. The assembly is Dual-Rank. Each rank is comprised eight 256Mbx8 DDR3-1600 SDRAMs.One EEPROM is used for Serial Presence Detect.
Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology.
Features
- 204-pin JEDEC-compliant SO-DIMM, 67.60 mm wide by 30.00 mm high
- Operating Voltage: VDD = VDDQ = +1.35V (1.283V to 1.45V)
- Backward-compatible to VDD = VDDQ = +1.5V ±0.075V
- I/O Type: SSTL_15
- Data Transfer Rate: 12.8 Gigabytes/sec
- Data Bursts: 8 and burst chop 4 mode
- ZQ Calibration for Output Driver and On-Die Termination (ODT)
- Programmable ODT / Dynamic ODT during Writes
- Programmable CAS Latency: 5, 6, 7, 8, 9, 10 and 11
- Differential Data Strobe signals
- SDRAM Addressing (Row/Col/Bank): 15/10/3
- Fully RoHS Compliant
