The Edgecore CSR430 is an open disaggregated cell site gateway platform that provides a combination of 1/10/25 Gbps and 40/100 Gbps interfaces. Utilizing powerful Qumran family merchant silicon and an Intel Atom x86 processor, the device provides optimized performance for service provider access and aggregation networks.
The CSR430 has a temperature-hardened design and is able to operate at a wide operational temperature range from -40˚C to 65˚C. The redundant/hot swappable power modules and 4+1 high-efficiency modular fans provide high availability and hassle-free maintenance for mission-critical applications, making the hardware an ideal choice for current LTE and 5G mobile xHaul network solutions.
The CSR430 is pre-installed with ONIE (Open Network Install Environment) to provide freedom of choice and flexibility for preferred NOS (Network Operating System) integration with user applications.
Features
- Open disaggregated cell site gateway for mobile fronthaul, backhaul, and O-RAN networks.
- 20 x 25G SFP28 and 4 x 100G QSFP28 fixed ports.
- 2GB GDDR6 Deep packet buffer
- Temperature harden -40oC to 65oC compact 1U design
- 5G ready eCPRI, TSN and SRv6 enable
- Precise Time synchronization with GNSS, IEEE1588v2 and SyncE at Class C accuracy
- Latest 16nm ASIC with better power efficiency
- Rack mountable in standard 19″ racks.
- All ports, PSUs and fan modules are front access.
- Hot-swappable, load sharing, redundant AC/48VDC PSUs.
- Maintenance activity to replace PSUs and FANs can be done from the front panel without remove the product from rack.
- Side to side airflow
- 4+1 redundant fans, hot-swappable fan tray.
- Management: Ethernet and console RJ-45 ports; USB storage port.
- Pre-loaded with Open Network Install Environment (ONIE).
- Compatible with Open Network Linux (ONL).
