Gigabyte B840M DS3H WiFi 6 Micro ATX Motherboard – Intel 14th/13th/12th Gen CPU Support, PCIe 5.0, DDR4 5333MHz (OC), Dual M.2, 2.5GbE LAN - B840M DS3H WF6

The Gigabyte B840M DS3H WIFI6 Micro ATX Motherboard is a robust and versatile platform designed to support AMD Ryzen 9000, 8000, and 7000 Series processors, offering a solid foundation for gaming, productivity, and multimedia builds. Built with GIGABYTE’s Ultra Durable technology, it features an 8+2+2 digital VRM design for stable power delivery, ensuring reliable performance for high-performance CPUs. The motherboard supports up to 256GB of DDR5 memory across four DIMMs with AMD EXPO and XMP profiles, enabling overclocking up to 8200 MT/s for superior memory performance. Equipped with two PCIe 4.0 M.2 slots and four SATA 6Gb/s connectors, it provides high-speed storage options with RAID support. Advanced connectivity includes Wi-Fi 6, 2.5GbE LAN, USB-C 3.2 Gen 1, and triple-display support via HDMI and dual DisplayPorts. The comprehensive thermal design, featuring M.2 Thermal Guard and durable heatsinks, prevents throttling and maintains efficiency. DIY-friendly features like WIFI EZ-Plug, PCIe EZ-Latch, Q-Flash Plus, and an intuitive UC BIOS simplify assembly and system management. Enhanced by AI-driven technologies such as D5 Bionic Corsa, AORUS AI SNATCH, and HyperTune BIOS, along with X3D Turbo Mode for up to 18% gaming performance boost, this motherboard delivers a balance of performance, connectivity, and ease of use in a compact Micro ATX form factor, ideal for modern PC builds.

Features

Durable Performance

• Digital 8+2+2 VRM Design: Features 8 VCORE, 2 SOC, and 2 MISC phases for consistent, high-powered performance, supporting AMD Ryzen 9000/8000/7000 processors for reliable overclocking and system stability.

• DDR5 Overclocking up to 8200 MT/s: Supports up to 256GB of DDR5 memory across four DIMMs with dual-channel architecture, AMD EXPO, and XMP support, delivering top-tier compatibility and performance for gaming and multitasking.

• PCIe 4.0 Hardware Design: Includes one PCIe 4.0 x16 slot (supports x16 mode for Ryzen 9000/7000, x8 for Ryzen 8000 Phoenix 1, x4 for Phoenix 2) and one PCIe 3.0 x4 slot, optimized for graphics cards and NVMe SSDs.

• D5 Bionic Corsa: AI-driven overclocking technology enhances CPU and memory performance for peak system efficiency.

• AORUS AI SNATCH (Coming Soon): AI-powered auto-overclocking software for one-click performance optimization, maximizing CPU and memory potential.

• HyperTune BIOS: AI-driven BIOS optimization for advanced performance tuning, offering intuitive controls for overclocking and system adjustments.

• AI-Driven PCB Design: Optimizes signal integrity and performance through AI-enhanced PCB layout, reducing interference and improving reliability.

Comprehensive Thermal

• M.2 Thermal Guard: Prevents throttling in high-speed M.2 SSDs by dissipating heat, ensuring consistent performance under heavy workloads.

• Advanced Thermal Design: Durable full-metal heatsinks maintain system cooling and efficiency, supporting sustained performance during intensive tasks.

Future Connectivity

• Wi-Fi 6 and Bluetooth 5.3: Realtek Wi-Fi 6 RTL8851BE supports 802.11ax with speeds up to 2.4Gbps on 2.4/5 GHz bands and Bluetooth 5.3 for enhanced range and transmission, ideal for gaming and streaming.

• 2.5GbE LAN: Realtek 2.5GbE LAN delivers lightning-fast network speeds (2.5 Gbps/1 Gbps/100 Mbps), minimizing lag for competitive gaming and responsive applications.

• Triple-Display Support: Features one HDMI 2.1 port (4096x2160@60 Hz) and two DisplayPort 1.4 ports (3840x2160@144 Hz) for versatile, high-resolution display configurations with HDR and HDCP 2.3 support.

• High-Speed Storage: Includes two PCIe 4.0 x4/x2 M.2 slots (type 2580/2280 and 22110/2280) with RAID 0, 1, 5 (Ryzen 9000 only), and 10 support, plus four SATA 6Gb/s connectors for flexible storage solutions.

• USB Connectivity: Offers one USB-C 3.2 Gen 1 port on the back panel, one internal USB-C header, three USB 3.2 Gen 1 ports, and eight USB 2.0/1.1 ports for robust peripheral support.

Hi-Fi Audio

• High-End Audio Solution: Realtek Audio CODEC with high-quality capacitors and Audio Noise Guard supports 2/4/5.1/7.1-channel high-definition audio, delivering immersive sound for gaming and multimedia.

• Audio Noise Guard: Isolates analog audio components at the PCB level to reduce noise interference, ensuring high-fidelity audio output.

Easy and Friendly Design

• WIFI EZ-Plug: Simplifies Wi-Fi antenna installation with a quick-connect adapter, streamlining setup for DIY builders.

• PCIe EZ-Latch: Enables easy removal of graphics cards from the PCIe x16 slot, simplifying upgrades and maintenance.

• Q-Flash Plus: Allows BIOS updates without CPU, memory, or GPU installed, using a USB flash drive and onboard button for hassle-free firmware updates.

• EZ Debug Zone: Centralized debug LEDs and control buttons (reset and Clear CMOS jumpers) for efficient troubleshooting during system builds.

• UC BIOS with Q-Flash Auto Scan: Features a user-centered interface with Multi-Theme support, AIO Fan Control, and automatic BIOS file scanning for intuitive performance tuning and updates.

• Gigabyte Control Center with RGB Fusion: Unified software platform for system management and customizable RGB lighting via two addressable RGB Gen2 LED headers and one RGB LED header, integrated with HWiNFO co-branded OSD for real-time monitoring.

• X3D Turbo Mode: One-click BIOS feature boosts gaming performance by up to 18% for Ryzen 9000/8000/7000 processors, optimizing frame rates and reducing latency.

Ultra Durable Build

• UD Power Connector: Solid-pin 24-pin ATX and 8-pin CPU power connectors enhance conductivity and durability for reliable power delivery.

• Micro ATX Form Factor: Compact 24.4cm x 24.4cm design balances performance and space efficiency, ideal for gaming and productivity builds.

• Trusted Platform Module (TPM) Header: Supports GC-TPM2.0 SPI V2 module for enhanced security features.
