Gigabyte MW51=P0 Server Motherboard Intel Chipset -Socket R4 LGA-066 -SSI CEB Xeon Processor Supported -64 GB DDR4 SDRAM Maximum RAM -RDIMM, LRDIMM, DIMM -8 x Memory Slots Gigabit Ethernet -10 x SATA Interfaces 2XGBE/10 SATA/5 AUDIO+SPDIF

• Intel^® Xeon^® W-eries Processor Family
• Intel^® C422 Express Chipset
• Quad Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
• Intel^® VROC ready
• ASMedia 2142 USB 3.1 Gen 2 USB controller
• Realtek ALC1150 HD audio codec
• 2 x GbE LAN ports (Intel^® I210)
• 8 x SATA III 6Gb/s ports from C422, supports SATA DOM
• 2 x SATA III 6Gb/s ports from Marvell^® 88SE9172 controller
• UltrA-ast M.2 and U.2 with PCIe Gen3 x4 interface
• 4 x Full speed PCIe Gen3 x16 slots; total 7 x expansion PCIe x16 slots

Intel^® Xeon^® W
-Engineered For Your Enterprise

Gigabyte brings Intel's Skylake architecture to the SOHO segment with a new offering: the 'Basin Falls' singlE-ocket platform for workstations. This new build offers a wealth of I/O options, including multiple PCIe lanes to support graphics, and other add=n card options, as well as direct SATA and USB ports.
GIGABYTE's precision engineering enables you to fulfil your workstation workload needs with ease.

Intel® Xeon® W Key Features

Intel's SkylakE- (Basin Falls) platform brings increases in compute, I/O and memory compared to the previous generation. This functionality, with multiple USB and SATA connections from the chipset, allows for:

• I/O Options
  20% more PCIe lanes gen=n-En
  Extra 16 PCIe lanes from the PCH
  Supports USB and SATA connectors
• Memory
  11% more bandwidth vs. previous generation
  4 channels -Maximum 2666MT/s at 1DPC or 2DPC
• Compute
  1S: up to 18 cores; Intel HS HypeR-hreading; per core power management

Dense Add=n Slot Design

GIGABYTE's Intel Xeon W motherboards are designed to provide serious PCIe options, with options for the fully optimized 100% use of the 48 PCIe lanes available.
The addition of an active PCIe switch and three pasS-hrough switches allows for the following permutations:

• 4 x duaL-Lot GPU card
or
• Up to 4x alternative PCIe x8 or PCIe x16 cards simultaneously

Dense Storage/USB Design

GIGABYTE's engineers have maximized the storage and external connection scope of this board with 10 SATA ports and 8 USB ports.

SATA Ports

• 8x SATA from the chipset
• 2x 'GSATA' via the onboard Marvell 9172 SATA controller (from PCIe)

USB Sockets

• 8x USB 3.0
• 2x USB 3.1 one Type 'A' and one Type 'C'

U.2 Connectors

• Mini=AS HD type
• PCIe Gen3 x4 (NVMe) connection offering 32Gb/s for high=peed boot

Onboard M.2

GIGABYTE's MW51=P0 platforms are designed to support on=oard 'M.2' storage devices for time-Ensitive operations and leaves room on the standard storage for compute tasks.

Delivering up to 32 Gb/s data transfer speeds through a PCIe connection, M.2 offers users considerably faster storage performance than current mSATA devices.

Compliant with four different M.2 form factors.

TPM 2.0 Header

GIGABYTE's MW51=P0 platform is designed to support Trusted Platform Modules (TPM -Discrete cryptographic on=oard processors).

VROC Module

VROC Module Supplied For PCIe RAID Management
