Hikvision 1080P 1/2.9”CMOS Infrared Array Front And Rear Binocular Analog Camera -AE-VC263T-ITS(2.1+2.1mm)
- Progressive scan CMOS
- Up to 1080P resolution
- Min. illumination: 0.1 Lux @(F1.2, AGC ON), 0 Lux with IR
- Day & night switch supports auto electronic (inside view) and fix on colour (outside view)
- Supports auto white balance
Specification
Camera
- Shutter Speed: 1/25 s to 1/30,000 s
- P/N: P (Default format is PAL and support switching to NTSC)
- Wide Dynamic Range: NA
- Day & Night:
Inside vehicle view: Electronic Day to Night
Outside vehicle view: Fix on Colour
Lens
- Lens Mount: M12
Video
- Frame Rate: 1080P@25 fps
- SNR: 42 dB
Interface
- Video Output: TVI
- Built-in Microphone: Yes
- Built-in Speaker: No
- Audio: Yes
- Interface Style:
1 Vpp Composite Output (aviation plug or BM4F plug )
Aviation plug：1: video, 2: Audio, 3: power, 4: ground
Supplement Light Unit
- Power Supply: 9 to 16 V DC
- Power Consumption:
Front: 1.5W MAX
Rear: 2 W MAX
General
- Camera Material: Plastic
- Camera Dimension: 171mm × 77.29 mm × 68.07mm
- Start-up and Operating Conditions: -40 °C to 75 °C (-40 °F to 167 °F), 90%
