Hikvision 4 MP iBeacon Guidance Camera - DS-TCP440-B

• Built-in high-performance algorithm, supporting ANPR (accuracy ≥ 99.5%), detection of the parking space status (accuracy ≥ 99.99%), and smart analysis of crossing over line, motion detection, etc.
• HD 4.0 MP camera, applied in environment with low illumination such as underground garage.
• 3D noise reduction to guarantee clean and exquisite image.
• Smart detection of the parking space status, and smart analysis of crossing over line, motion detection, etc.
• Energy-saving LED with high brightness and low consumption.
• Speed recognition in second accuracy to indicate the parking space status in real time and provide accurate available parking space number
• Network wiring with easy connection, installation, and maintenance.
• ROI encoding.
• Two RJ45 interfaces, supporting connecting cameras in series, and no power cord is needed.
• Built-in iBeacon module, supporting indoor positioning and navigation with the help of APP. iOS or Android SDK is provided.

Specification

Camera

• Min. Illumination;

Color: 0.019 Lux @ (F1.9, AGC OFF)

B/W: 0.011 Lux @ (F1.9, AGC OFF)

• Sensor Type: 1/3" Progressive Scan CMOS
• Max. Resolution: 2560 × 1440
• Day/Night Switch: Supported
• Shutter: 1 to 1/100,000 s
• Number of Detected Parking Space: Max 3

Lens

• Lens Type;

  2.8 mm

  4 mm

• Aperture;

  2.8 mm：F2.0

  4 mm：F2.0

• Focal Length & FoV;

  2.8 mm, horizontal FoV: 103.7±5°, vertical FoV: 56.1±5°, diagonal FoV: 121.8±5°,

  4 mm, horizontal FoV: 81.3±5°, vertical FoV: 43.9 ±5°, diagonal FoV: 97±5°

• Focus: Fixed

General

• Resolution: 4 MP
• Working Temperature & Humidity: -20 °C to 50 °C (-4 °F to 122 °F)
• Consumption: Max. 6.5 W
• Weight: 0.525 kg (1.1 lb.)
• Working Temperature and Humidity;

-20 °C to 70 °C (-4 °F to 158 °F)

5% to 95% @ 40°C (non-condensing)

• Working Environment: 90% or less (non-condensing)
• Power Supply: Hikvision PoE, or 12 to 24 VDC wide-range voltage
• Dimensions: 170 × 121 × 105 mm (6.7 × 4.8 × 4.2 inch)
• Weight:  (with Package)1 kg (2.2 lb.)
• Dimensions (with Package): 275 * 205 * 175 mm(10.8 * 8.1 * 6.9 inch)
• Storage Temperature and Humidity;

Temperature: -20 °C to 70 °C (- 4°F to 158 °F)

Humidity: 95% (non-condensing)
