Hikvision 8 MP Smart Hybrid Light with ColorVu Fixed Mini Dome Network Camera
- High quality imaging with 4 MP resolution
- Efficient H.265+ compression technology
- Clear imaging against strong backlight due to 130 dB WDR technology
- Built-in microphone for real-time audio security(-U)
- Focus on human and vehicle targets classification based on deep learning
- 24/7 colourful imaging
- Water and dust resistant (IP67)
Specification
Camera
- Image Sensor: 1/1.8" Progressive Scan CMOS
- Resolution: 2688 × 1520
- Illumination: Colour: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time: 1/3 s to 1/100,000 s
- Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
- Lens Type: Fixed focal lens, 2.8, 4, and 6 mm optional
- Focal Length & FOV:
2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134°
4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115°
6 mm, horizontal FOV 58°, vertical FOV 31°, diagonal FOV 69°
- Lens Mount: M16
- Iris Type: Fixed
- Aperture: F1.0
- Depth of Field:
2.8 mm, 2.5 m to ∞
- mm, 3.5 m to ∞
6 mm, 7.5 m to ∞
DORI
- DORI:
2.8 mm, D: 58 m, O: 23 m, R: 11 m, I: 6 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
6 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
Illuminator
- Supplement Light Type: White Light
- Supplement Light Range: Up to 30 m
- Smart Supplement Light: Yes
General
- Power:
12 VDC ± 25%, 0.55 A, max. 6.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.22 A to 0.13 A, max. 7.6 W
- Dimension: Ø138.3 mm × 125.2 mm (Ø5.4" × 4.9")
- Package Dimension: 170 mm × 170 mm × 150 mm (7" × 7" × 5.9")
- Weight: 750 g (1.7 lb.)
- With Package Weight: 1055 g (2.3 lb.)
- Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language:
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General Function Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
