Hikvision 8 Port Gigabit Smart Managed Industrial POE Switch -DS-3T1512HP-SI-8P4F
- 8 x Gigabit PoE RJ45 ports,4 x Gigabit SFP fiber optical ports
- Support 802.1Q VLAN
- Support 802.3bt Hi-PoE, Max. 90W for one port
- Support STP/RSTP/ERPS Loop prevention, storm control
- Support cable detection to locate failure
- Support SNMP, QoS, DHCP snooping
- 6 kV Surge Protection
- Wider Temperature (-40 °C to 75 °C) Design
- Up to 300 m Long-range Transmission
Specification
General
- Shell: Metal material, IP40
- Net Weight: 0.84 kg (1.85 lb)
- Gross Weight: 1.16 kg (2.56 lb)
- Dimensions (W × H × D): 155.00 mm × 46.00 mm × 130.00 mm (6.10'' × 1.81'' × 5.12'')
- Operating Temperature: -40 °C to 75 °C (-40 °F to 167 °F)
- Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity: 5% to 95% (no condensation)
- Relative Humidity: 5% to 95% (no condensation)
- Power Supply:
48~57 V DC, 7.5 A
52 V~57 V recommended input voltage to ensure stable power supply.
Support dual power inputs and hot backup.
- Installation Mode: Desk-Mounted,Rail
- Max. Power Consumption: 307 W
- Power Consumption in Idle: 7 W
- Surge Protection: 6 KV
Network Parameters
- Ports: 8 × Gigabit PoE port,4 × Gigabit fiber optical port
- MAC Address Table: 8 K
- Switching Capacity:
Whole-Device Performance: 56 Gbps
Port Performance: 24 Gbps
- Packet Forwarding Rate:
Whole-Device Performance: 41.66 Mpps
Port Performance: 17.86 Mpps
- Internal Cache: 4.1 Mbits
