• High quality imaging with 9 MP resolution(1'' GMOS)
• Efficient H.265 compression technology
• Large storage capacity, up to 500 GB SSD
• Speed detection ranged from 10 to 320 km/h
• Convenient debugging with 720P touch screen
• Dismountable built-in lithium battery for power supply
• Smart functions: license plate recognition (LPR)

Specification

Camera

• Image Sensor: 1″ Progressive Scan GMOS
• Max. Resolution: 4096 × 2160
• Min. Illumination: 0.1 Lux @ (F1.2, AGC ON)
• Shutter Time: 1/25 s to 1/100,000 s

Lens

• Lens Type: DC drive
• Iris Type: C/CS Interface

Illuminator

• Flashlight Control: Supports light control/time control

Radar

• Working Frequency: 24.15 GHz ± 45 MHz
• Speed Range: 10 to 320 km/h
• Speed Measurement Accuracy: -2 to 2 km/h
• Trigger Mode: Trigger vehicle head, trigger vehicle tail, and trigger vehicle head and tail
• Antenna Beam Width: 4.9 × 17.3°

Video

• Main Stream: 50Hz: 25 fps (4096 × 2160, 3392 × 2008, 2944 × 1656, 1920 × 1080, 1280 × 720, 704 × 576)↵ 60 Hz: 30 fps (4096 × 2160, 3392 × 2008, 2944 × 1656, 1920 × 1080, 1280 × 720, 704 × 576)
• Sub-Stream:

50 Hz: 25 fps (3392 × 2008, 2944 × 1656, 1920 × 1080, 1280 × 720, 704 × 576)

60 Hz: 30 fps (3392 × 2008, 2944 × 1656, 1920 × 1080, 1280 × 720, 704 × 576)

• Third Stream:

50 Hz: 30 fps (1280 × 720)

60 Hz: 30 fps (1280 × 720)

• Video Compression: JPEG encoding
• Video Bit Rate: 32 Kbps to 16 Mbps

Network

• Protocols: TCP/IP, HTTP, DHCP, DNS, RTP, RTSP, NTP, FTP
• Simultaneous Live View: Up to 6 channels
• APIONVIF (PROFILE T, PROFILE S, PROFILE G), ISAPI, SDK
• User/Host: Up to 16 users

3 user levels: administrator, operator and user

• Security:

Password protection, HTTPS encryption, digest authentication for HTTP/HTTPS, digest

authentication for ONVIF (Version 2.1)

• Network Storage: Built-in solid state disk (500 GB)
• Client: iVMS-4200 (Only for video live view and LPR information search)
• Web Browser: IE8-IE11, plug-in free live view supported


• Image Settings:

Saturation, brightness, contrast, white balance, gain and 3D DNR are adjustable via client

software.

• Day/Night Switch: Auto/Scheduled/Triggered by alarm in
• Image Enhancement: BLC, HLC, 3D DNR
• Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24-bit bmp format.

• Supplement Detection (Satellite Positioning):
• Satellite Positioning: GPS

Interface

• Video Output: 3 outputs for flashlight control
• Ethernet Interface: 1 RJ45 10M/100M/1000M Ethernet interface
• USB1 USB 3.0

Event

• Basic Event:

HDD Error, network disconnected, IP address conflicted, vehicle detector exception, traffic light

detector exception

Road Traffic and Vehicle Detection

• Coverage: Up to 3 lanes
• Smart Function: License Plate Recognition
• LPR Countries/Regions

Middle East:

The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain

Africa:

Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria

Asia-Pacific:

Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka

America:

Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala

Europe:

Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina

Russian-Speaking Regions:

Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan

• Accuracy (Under recommended installation and lighting conditions)

Capture rate:  > 90%

LPR accuracy: > 95%

Mistaken capture rate: < 3%

• No License Plate Detection: Supported

General

• Operating System: Linux
• Power: 19 VDC, Max.25 W, and embedded 10.8V lithium battery
• Weight: Approx. 9 kg (19.84 lb)
• Operating Condition:

Temperature: -20 °C to +60 °C (-4 °F to +140 °F)

Humidity: 90% or less (non-condensing)

• General Function: One-key reset, three streams, heartbeat, password protection, watermark and NTP time sync.

Approval

• Protection: IP54
