Hikvision DS-C60S-02HO/4K HDMI Output Board(4K)

• The 4K HDMI output board supports YUV 444 output and 2 channels of 4K 30 fps HDMI output or 1 channel of 4K 60 fps HDMI output.
• Supports composite audio output.

Specifications

Chassis

• Occupied Slot: Output slot

Video Wall

• Layers: 16 layers per port (2K/4K)

Video Output

• Video Output Interface Type: HDMI 2.0
• Video Output Interfaces: 2
• Video Output Resolution;

4096 × 2160@60 Hz, 3840 × 2160@60 Hz, 4096 × 2160@30 Hz, 3840 × 2160@30 Hz,

2560 × 1600@60 Hz, 2560 × 1440@60 Hz, 1920 × 1200@60 Hz, 1920 × 1080@60 Hz

Supports LED screen, custom resolution output, 60 Hz loading output, and 8.84 MP loading with width ranging from 144 to 8192 and height ranging from 144 to 4320.

• Max. Video Output Resolution: 4K
• Loading Capacity for Video Output to LED;

Single port load 8840000,

Width 144 - 8192,

Height 144 - 4320;

Audio Output

• Audio Output Interface: HDMI composite audio
• Audio Output Interfaces: 2
