Hikvision DS-C60S HDMI Output Board Video Wall Controller - DS-C60S-04HO
- The HDMI output board provides 4 HDMI ports and supports YUV 444 output.
- Supports HDMI composite audio output.
DatasheetSpecifications
Chassis
- Occupied Slot: Output slot
Video Wall
- Layers: 16 layers per port (2K/4K)
Video Output
- Video Output Interface Type: HDMI 1.4
- Video Output Interfaces: 4
- Video Output Resolution;
1920 × 1200@60 Hz, 1600 × 1200@60 Hz, 1920 × 1080@60 Hz, 1680 × 1050@60 Hz,
1280 × 720@60 Hz, 1280 × 1024@60 Hz, 1024 × 768@60 Hz
Supports LED screen, custom resolution output, 60 Hz loading output, and 2.6 MP loading with width ranging from 144 to 4096 and height ranging from 144 to 2160.
- Max. Video Output Resolution: 1080P
- Loading Capacity for Video Output to LED;
Single port load 2600000,
Width 144 - 4096,
Height 144 - 2160
Audio Output
- Audio Output Interface: HDMI composite audio
- Audio Output Interfaces: 4
