Hikvision ECI-D12F4 2MP Outdoor Network Dome Camera with Night Vision & 4mm Lens
The ECI-D12F4 2MP Outdoor Network Dome Camera from Hikvision uses a 1/2.8" progressive scan CMOS sensor to capture 1920 x 1080 resolution video at 30 fps. IR LEDs provide up to 100' of night vision. The camera's 4mm fixed lens delivers an 86° horizontal field of view. Integrated PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable.
This dome camera is compliant with ONVIF profiles S and G, making it compatible with a wide range of surveillance devices. The camera's metal enclosure is IP67 and IK10 rated for outdoor use in areas at risk of vandalism.
- EXIR 2.0 technology for visibility in low-light conditions
- IR cut filter for day and night functionality
- 265+, H.265, H.264+, H.264, and MJPEG video compressions
- Slow shutter support
- Digital wide dynamic range
- 3D-DNR
- Backlight compensation
- Image settings include: saturation, brightness, contrast, sharpness, automatic gain control, and white balance
- Region of interest (ROI) for one fixed region (main stream and sub stream)
- Alarm triggers include: motion detection, video tampering alarm, and illegal login
- General functions include: anti-flicker, heartbeat, mirror, password protection, privacy masking, and watermark
- Up to 32 users with three host levels (admin, operator, and user)
- Up to six channels in simultaneous live view
- Compatible with Internet Explorer 7 or higher, Chrome 18 to 42, Firefox 5.0 or higher, Safari 5.02 or higher, iOS, Android, iVMS-4200, and Hik-Connect
- CSA, FCC, CE, and cUL certified
- TVS 2000V lightning, surge, and voltage transient protection
Key Specs
| Image Sensor |
1/2.8"-Type CMOS
|
| Focal Length |
4mm
|
| Field of View |
Horizontal: 86°
Vertical: 46°
Diagonal: 102°
|
| Pan/Tilt |
No
|
| Built-In Microphone |
No
|
| Power I/O |
1x DC
1x RJ45
|
Imaging
| Lens Mount |
M12
|
| Number of Lenses |
1
|
| Image Sensor |
1/2.8"-Type CMOS
|
| Sensor Resolution |
Effective: 2 Megapixel
|
| IR Cut Filter |
Yes Mechanical
|
| Day/Night |
Yes
|
Exposure Control
| Minimum Illumination |
0.028 Lux (Color)
0 Lux (Black and White)
|
Lens
| Focal Length |
4mm
|
| Field of View |
Horizontal: 86°
Vertical: 46°
Diagonal: 102°
|
| Maximum Aperture |
f/2
|
Video
| Automatic Gain Control |
Yes
|
| Max IP Streaming |
via RJ45
1920 x 1080 up to 30.00 fps
|
| Multi-View Streaming |
Yes
|
Control
| Camera Angle Adjustment |
Horizontal: 0 to 355°
Vertical: 0 to 70°
|
| Pan/Tilt |
No
|
Networking
| Security |
HTTPS, IEEE 802.1X, Password Protection, Watermark
|
| Supported Protocols |
Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, TCP, UDP, UPnP, ONVIF Profile G, ONVIF Profile S, ISAPI
|
Interface
| Media/Memory Card Slot |
No
|
| Other I/O |
1x RJ45
|
| Built-In Microphone |
No
|
System Integration
| Analytics |
Motion Detection
|
Sensors & Alarms
| Event Trigger |
Yes
|
| Event Action |
Recording, Notification, Alarm
|
Power
| Power I/O |
1x DC
1x RJ45
|
| Power Consumption |
Power Supply: 5 W
PoE: 7 W
|
General
| Material of Construction |
Metal
|
| Environmental Resistance |
Dust/Water-Resistant (IP67)
|
| Impact Resistance |
Impact-Resistant (IK10)
|
| Operating Conditions |
-22 to 122°F / -30 to 50°C up to 95% Humidity
|
| Illumination |
850 nm IR LEDs up to 100' / 30.48 m
|
| OS Compatibility |
Android/iOS
|
| Mobile App Compatible |
Yes: Android & iOS
|
| Dimensions (W x H x D) |
4.4 x 3.2" / 111 x 82.4 mm
|
| Weight |
0.9 lb / 410 g (Body Only)
|
Packaging Info
| Package Weight |
1.8 lb
|
| Box Dimensions (LxWxH) |
5.5 x 4.5 x 4"
|
