• Continuous light, IR light or white light source, 16 lamp beads
• Aluminium alloy light body, fin-type radiator, and high light transmission with tempering glass
• Infrared LED chips with long lifespan, good stability and high luminous efficiency
• Professional optical design, light uniformity and distinct target spot
• High beam light design with built-in automatic light control, open at low illumination
• Water and dust resistant (IP66)

Specification

Supplement Light

• Light Type: IR light
• IR Wavelength: 850nm
• LED Lamp Beads: 16
• Center Illuminance: 60 uW/㎡
• Angle of Light: 30°
• Effective Distance: 16 to 25 m
• Color:  Temperature:
• Service Life: ≥ 50000 Hours
• Coverage: 3 lane(s)

Function

• Day and Night Function: Support ambient brightness detection, and automatic start-up at low illumination

General

• Power:

AC 100 V to 240 V, 0.15 A, 33 W, two-core terminal block

• Material: Aluminium alloy
• Dimensions: 215.25 mm × 151 mm × 127.5 mm (8.47" × 5.94" × 5.02") (L × W × H)
• Package Dimensions: 290 mm × 247 mm × 230 mm (11.42" × 9.72" × 9.06") (L × W × H)
• Weight: Approx. 2.7 kg (5.90 lb.)
• With Package Weight: Approx. 3.5 kg (7.61 lb.)
• Operating Condition: -40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing)
• Storage Condition: -40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (Non-condensing)

Approval

• EMC: EN 50130-4:2011+A1:2014, EN 55032:2015+A11:2020+A1:2020, EN 61000-3-3:2013+A1:2019+A2:2021, EN IEC 61000-3-2:2019+A1:2021
• Safety:

CB: IEC 60598-1:2020, IEC 60598-2-5:2015, IEC 62031:2018, IEC TR 62778:2014,

CE-LVD: EN 60598-1, EN 60598-2-5, EN 62031

• Environment:

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006

• Protection:

IP66: IEC 60529: 1989+A1: 1999+A2: 2013

 Data Sheet
