Hikvision Wireless Tag Reader - DS-PT1-WB(B)
- 868MHz two-way wireless communication
- AES-128 encryption
- LED display, show the differernt feedbacks with easy understanding
- Operation: Stay arm/away arm/disarm by areas
- Arming process with fault confirm, more secure
- Patrol tag check in
- Front and rear panel tamper-proof
Specification
Hardware features
- Power switch: Power on/off
Display
- Indicator: 5, area(blue), fault(orange), arm(blue), disarm(green), alarm(red), signal(red/green)
Electrical characteristics
- Battery type: 3 × AA batteries
- Operation humidity: 10% to 90% (no condensing)
- Operation temperature: -10°C to 55°C (-4°F to +122°F)
- Power consumption:
Quiescent current: 110 uA
Max current: 292mA
Voltage: 1.5 VDC
- Battery life span: Up to 2 years (standby time)
Wireless transmission
- RF frequency: 868 MHz
- RF modulation: 2GFSK
- RF distance: 1200 m (open area)
General
- Installation method: Wall-mounting
- Dimension (WxHxD): 75 ×124 × 21 mm
- Color: white
- 183 g
