IO Crest M.2 to 1 Port RS232 and 1 Port RS232/422/485 Serial Controller Card - IO-ADA15070
PCIe 2.0 Gen 1 compliant,x1 Link, dual simplex, 2.5 Gbps in each direction,Suitable for M.2 slot with key M or B based on PCIe,Data read/write 32-bit operation,Global interrupt status register for both UARTs
Features
- PCIe 2.0 Gen 1 compliant
- x1 Link, dual simplex, 2.5 Gbps in each direction
- Suitable for M.2 slot with key M or B based on PCIe
- Data read/write 32-bit operation
- Global interrupt status register for both UARTs
- 16 multi-purpose inputs/outputs (MPIOs)
- Two independent UART channels controlled with
- Support Bits per second Data transfer rates from 300 baud to 921600baud
- 16550 compatible register Set
- 256-byte TX and RX FIFOs
- MCU enable controls RS485 bidirectional data signal
- RS232: DCD,RXD,TXD,DTR,GND,DSR,RTS,CTS,RI
- RS422: TX - ,TX+, RX +,RX - GND
- RS485: Data-, Data +
- Data bitsï¼4,5,6,7,8
- Stop bitsï¼1,1.5,2
- Parity bitï¼Odd, even, mark, space, None
- Flow controlï¼ Noneï¼Xon / Xoff, Hardware
- Operating Temperatureï¼-40°C to +85°C
- Storage Temperature:-65°C to +150°C
System Requirements
- Windows Server 2003, 2008, 2012,2016,2019
- Windows XP, Vista, 7, 8,8.1,10
- Linux 2.6.27, 2.6.31, 2.6.32, 3.x.x and newer
- One free M.2 key M or key B slot
Package Contents
- 1 × M.2 to RS232 +RS232/422/485 Card
- 1 × User Manual
- 2 × Low Profile
- 1 × CD Driver
