IO Crest PCIe 3.0x4 to 4 Ports USB3.2 Gen2 Type-A Host Controller Card - IO-PCE3142-4I
Provides four independent USB 3.2 Gen2 ports with a total bandwidth of 40Gbps,Up to 10Gbps transfer rate per USB 3.2Gen2 interface,It is a industrial level high performance USB card,Support PCI Express Gen-III x4
Features
- Provides four independent USB 3.2 Gen2 ports with a total bandwidth of 40Gbps
- Up to 10Gbps transfer rate per USB 3.2Gen2 interface
- It is a industrial level high performance USB card
- Support PCI Express Gen-III x4
- Supports x4, x8, x16 (lane) PCI Express Bus connector keys.
- Compliant with Universal Serial Bus 3.1 specification Gen2
- Compliant with USB Attached SCSI Protocol Revision 1.0
- Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 1.1
- Compliant with Universal Serial Bus 3.1 Specification Revisionv2.0/1.0
- Supports USB data transfer rate of 10G/5G/480/12/1.5 Mbps
- 5V/900mA power output for Type A port
- Power Input: 15-pin SATA CD-ROM Type Power Connector
- Built-in over current protection on each USB port
- Support device remote wakeup function from USB keyboard or mouse
- Support Control, Bulk, Stream, Interrupt, Isochronous transfer type
- Operation Temperature ï¼0 to 125°C
- PCIEX4design,compatible with PCIEX4,X8X16 slot.
System Requirements
- Windows 7 (X86/X64)
- Windows 8.x / 10 (X86/X64) (Windows in-box driver)
- Linux 2.6.31 or later (Linux OS already implemented USB3.0 driver)
Package Contents
- 1 × PCIe to 4 Ports USB3.2 Gen2 Type-A Card
- 1 × User Manual
- 1 × Low Profile Bracket
