IO Crest PCIe to 2 Ports RS232 DB9 Serial Controller Card - IO-PCE382-2S
Fully Compliant with PCI-Express Base Specification, Revision 1.0a,PCIe Multi Function Peripheral Controller with x1 Lane Interface,Support for D1, D2, D3hot and D3cold,Supports PCIe Power Management.
Features
-
WCH382 Chipset
-
Fully Compliant with PCI-Express Base Specification, Revision 1.0a
-
PCIe Multi Function Peripheral Controller with x1 Lane Interface
- Support for D1, D2, D3hot and D3cold
-
Supports PCIe Power Management
-
Serial Ports:16C450/550/Extended 550 Compatible UARTs
-
Supports RS232, RS485 & RS422 Modes
-
Bi-directional Speeds from 50 bps to 16Mbps/Port
-
Full Serial Modem Control
-
Supports Hardware, Software Flow Control
-
5, 6, 7, 8 and 9-bit Serial Format Supported
- Even, Odd, None, Space & Mark Parity Supported
-
Custom BAUD Rates Supported with External Clock or by Programming Internal PLL
-
On Chip 256 Byte Depth FIFOs in Transmit, Receive Path of Each Serial Port
-
Supports Remote Wake-up and Power Management Features
-
Serial Port Transceiver Shutdown Supported
-
Supports Slow IrDA on All Serial Ports
