IO Crest USB3.0 to Single Port Gigabit Ethernet Network Adapter - IO-USB8153D-GLAN
Use a RTL8153 chipset controller combines an IEEE 802.3u compliant Media Access Controller (MAC). The RTL8153 offers high-speed transmission over CAT 5 UTP cable or CAT 3 UTP (10Mbps only) cable.
Features
- Integrated 10/100/1000M transceiver
- Supports USB 3.0, 2.0, and 1.1
- Supports CDC-ECM
- Supports LPM (Link Power Management)
- Supports pair swap/polarity/skew correction
- Crossover Detection & Auto-Correction
- Supports Wake-On-LAN and ‘RealWoW!’
- Supports power down/link down power saving
- Supports hardware CRC (Cyclic Redundancy Check) function IEEE
- Supports Full Duplex flow control (IEEE 802.3x)
- Fully compliant with IEEE 802.3 and IEEE 802.3u
- Supports IEEE 802.1P Layer 2 Priority Encoding
- Supports IEEE 802.1Q VLAN tagging
- Supports IEEE 802.3az-2010 (EEE)
- Microsoft AOAC (Always On Always Connected)
- Supports 16-set 128-byte Wake-Up Frame pattern exact matching
- Supports link change wake up
- Supports Microsoft WPD (Wake Packet Detection)
- Supports Protocol Offload (ARP & NS)
- Intel CPPM (Converged Platform Power Management)
- Supports L1 with 3ms BESL (USB 2.0)
- Dynamic LTM messaging (USB 3.0)
- Supports U1/U2 (USB 3.0)
- Supports selective suspend
Package Contents
- 1x USB 3.0 Ethernet Adapter
- 1x Quick Installation Guide
- 1x USB3.0 cable
System Requirements
- Windows Server 2003,2012, XP , Vista ,7,8,10, 32 and 64 bit
- Windows Server 2008 32_bit
- Linux, and Mac
- One available USB port
Applications
- USB 10/100/1000M Ethernet on Motherboard, Dongle, Notebook, Docking station, or Embedded system
