Kingston Technology ValueRAM . Component for: PC/Server, Internal memory: 8 GB, Memory layout (modules x size): 1 x 8 GB, Internal memory type: DDR4, Memory form factor: 288-pin DIMM, CAS latency: 19
This document describes ValueRAM's KVR26N19S6/8 is a 1G x 64-bit (4GB) DDR4-2666 CL19 SDRAM (Synchronous DRAM), 1Rx16, memory module, based on four 1G x 16-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-2666 timing of 19-19-19 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
Documents
Specifications
| General | |
|---|---|
| Brand | Kingston Technology |
| Manufacturer part number | KVR26N19S6/8 |
| HSSL part number | UK-KIN-KVR26N19S6/8 |
| UPC / GTIN | 0740617311310 |
| Product type | Memory Modules |
| Features | |
| CAS latency | 19 |
| Internal memory | 8 GB |
| Memory layout (modules x size) | 1 x 8 GB |
| Internal memory type | DDR4 |
| Memory data transfer rate | 2666 MT/s |
| Component for | PC/Server |
| Memory form factor | 288-pin DIMM |
| ECC | No |
| Buffered memory type | Unregistered (unbuffered) |
| Memory ranking | 1 |
| Memory voltage | 1.2 V |
| Row cycle time | 45.75 ns |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| SPD profile | Yes |
| JEDEC standard | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 85 °C |
| Storage temperature (T-T) | -55 - 100 °C |
| Sustainability | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 133.3 mm |
| Height | 31.2 mm |
| Other features | |
| Doesn't contain | Halogen |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number UK-KIN-KVR26N19S6/8.
