PROCESSOR

Supports AMD^® Ryzen 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Processors for Socket AM4

CHIPSET

AMD^® X370 Chipset

MEMORY

• 4 x DDR4 memory slots, support up to 128GB *ComboPI 1.0.0.3-based and above BIOS are required.
  • Supports DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/ 3200(OC)+ Mhz
• Dual channel memory architecture

1. A-series / Athlon™ X4 processors support a maximum of 2400 MHz; Please refer to www.msi.com for more information on compatible memory

SLOTS

• 2 x PCIe 3.0 x16 slots (PCIE_2, PCIE_4)
  • RYZEN series processors support x16/x0, x8/x8 mode
  • Ryzen™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 processors support x8/x0 mode
  • AMD^® Athlon™ with Radeon™ Vega Graphics processors support x4/x0 mode
• 1 x PCIe 2.0 x16 slot (PCIE_6, supports x4 mode)
• 3 x PCIe 2.0 x1 slots

1. Please refer to the manual for details

ONBOARD GRAPHICS

• 1 x HDMI™ 2.0 port, supports a maximum resolution of 4096x2160@60Hz
• 1 x DisplayPort, supports a maximum resolution of 4096x2160@60Hz

1. Only support when using AMD^® Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics and A-series Processors
2. Maximum shared memory of 2048 MB

MULTI-GPU

• RYZEN series processor
  • Supports 2-Way Nvidia^® SLI™ Technology
  • Supports 3-Way AMD^® CrossFire™ Technology
• AMD^® Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Processors
  • Supports 2-Way AMD^® CrossFire™ Technology

STORAGE

AMD^® X370 Chipset

• 6 x SATA 6Gb/s ports
• 2 x M.2 ports (Key M)
  • M2_1 slot supports PCIe 3.0 x4 (RYZEN series processor) or PCIe 3.0 x2 (AMD^® Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Processors) and SATA 6Gb/s 2242/ 2260 /2280/ 22110 storage devices
  • M2_2 slot supports PCIe 2.0 x4 and SATA 6Gb/s 2242/ 2260 /2280 storage devices
• 1 x U.2 port
  • Supports PCIe 3.0 x4 (RYZEN series processor) or PCIe 3.0 x2 (AMD^® Athlon™ with Radeon™ Vega Graphics and A-series / Athlon™ X4 Processors) NVMe storage

1. Maximum support 2x M.2 PCIe SSDs + 6x SATA HDDs or 2x M.2 SATA SSDs + 4x SATA HDDs.

RAID

AMD^® X370 Chipset

• Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

USB

AUDIO

Realtek^® ALC1220 Codec

• 7.1-Channel High Definition Audio
• Supports S/PDIF output

LAN

• 1 x Intel^® I211AT Gigabit LAN controller

INTERNAL CONNECTORS

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x 4-pin ATX 12V power connector
• 1 x 6-pin ATX PCIe power connector
• 6 x SATA 6Gb/s connectors
• 2 x USB 2.0 connectors (support additional 4 USB 2.0 ports)
• 2 x USB 3.1 Gen1 connectors (support additional 4 USB 3.1 Gen1 ports)
• 1 x USB 3.1 Gen2 connector (supports additional 1 USB 3.1 Gen2 Type C port)
• 1 x 4-pin CPU fan connector
• 1 x 4-pin water-pump-fan connector
• 4 x 4-pin system fan connectors
• 1 x RGB LED connector
• 1 x Digit Debug Code LED
• 1 x 2-pin Slow mode connector
• 1 x TPM module connector
• 1 x Front panel audio connector
• 2 x System panel connectors
• 1 x Chassis Intrusion connector

BACK PANEL PORTS

DIMENSIONS

• 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
• ATX Form Factor

MOUNTING

9 mounting holes

OPERATING SYSTEM

• Support for Windows^® 10 64-bit
• Support for Windows^® 7 64-bit
