Omnitron Small Form Pluggable 10 Gigabit SFP+ and XFP optical transceivers are interchangeable compact fiber connectors that enable a single network device to connect to a wide variety of fiber optic cable types and distances.
Omnitron CWDM/DWDM Optical Transceivers are used to customize iConverter® products to meet specific networking protocols and media requirements. They support single-mode dual fiber applications with Coarse Wave Division Multiplexing (CWDM) and Dense Wave Division Multiplexing (DWDM) wavelengths.
CWDM/DWDM Optical Transceivers increase network capacity by transmitting multiple data channels using separate optical wavelengths on the same fiber pair.
CWDM Optical Transceivers support wavelengths 1270nm to 1610nm in 20nm increments. The CWDM wavelengths are compliant to the ITU G.694 CWDM standard.
DWDM Optical Transceivers support wavelengths between 1525-1565 nm (C band) with 100GHz spacing.
Optical Transceivers reduce network equipment inventories by eliminating the need to maintain surplus units/ devices of various fiber types for network repairs or upgrades. They also enable network upgrades by providing interchangeable fiber connectors that can easily adapt to and modify any existing network. For example, a media converter that was originally used in a single-mode network can be re-configured to operate over a CWDM/DWDM network by simply replacing the pluggable optical transceiver.
Based on the MSA SFF-8472 standard, CWDM/DWDM Optical Transceivers support digital diagnostic capabilities, providing enhanced diagnostic information to assist network administrators with network maintenance and management. When used in iConverter modules managed by Omnitron's NetOutlook® SNMP Network Management Software with intuitive Graphical User Interface or third party SNMP software, CWDM/DWDM Optical Transceivers can collect enhanced, real time optical diagnostic information including fiber optic TX and RX power, voltage and transceiver temperature.
By providing compact physical size and the ease of interchangeability, Omnitron Optical Transceivers provide a cost-effective and flexible solution for fiber optic network design.
- Compatible with iConverter 10G media converter modules and Network Interface Devices that support SFP+ and XFP transceivers
- Supports Coarse Wave Division Multiplexing optics
- Supports standard wavelengths in the spectrum defined by ITU-T G.694.2
- Supports Dense Wave Division Multiplexing (DWDM) optics
- Supports standard channels in the spectrum defined by ITU Grid C-Band, 100GHz - spacing
- Compliant with MSA SFF-8472 standard, which provides interoperability with other network devices
- Compliant with IEEE 802.3ae 10 Gigabit Ethernet specifications
- Digital Diagnostic capability
- Compliant with RoHS2 (6/6), WEEE and REACH
- Low EMI metal enclosure
