4U 24-bay, LFF
Dual-active or Single-upgradable controller
Intel® Xeon® 4-core processor (8-core processor models are also available
| 4U | Dual Ctrl | Intel D-1508 Dual Core | 4GB DDR4 ECC Memory (Max. 64GB) per controller | 24 HDD | 3.5"/2.5" 12Gb SAS/NL SAS 2.5" SAS/SATA SSD* (Need optional MUX board) | 4 std. + 16 (optional) | 4 | 286 Max HDD |
| Dual-Controller SAN System, iSCSI, RAID 0,1, 5, 6, 10, 50, 60, global hot spare, max 128GB RAM, 4-ported 10GbE BASE-T iSCSI, redundant power supply, 4 slots for optional host cards ( Slot 1: Optional host cards for 16Gb X 4 ports Fibre Channel, or 10Gb X 4 ports iSCSI, or 1Gb X 4 ports iSCSI card; Slot2: 10Gb X 4 ports iSCSI, or 1Gb X 4 ports iSCSI card) . RAIL kit (optional). LVM5: 4096 LUNs (max), 64HDDs in one RAID group, local cloing, volume snapshot (4096 snapshots/system, 64 snapshots/LUN, 64 LUNs), remote-replicaiton, thin-provisioning, SSD caching (optional), auto-tiering w/ 3-tier (optional) |
Built-in 2 x 10GBASE-T iSCSI (RJ45) ports
Built-in 1 x 1GbE management port
Mix & match 3.5" & 2.5" SAS, NL-SAS, SED HDD
2.5” SAS, SATA² SSD
Up to 10 expansion units using XD5324 (LFF 24-bay), XD5316 (LFF 16-bay), XD5312 (LFF 12-bay), XD5326 (SFF 26-bay) 12Gb SAS expansion enclosure
Up to 4 expansion units using XS5360 (LFF 60-bay) 12Gb SAS expansion enclosure
Cache-to-Flash module (optional)
Battery backup module + Flash module (To protect all memory capacity)
Super capacitor module + Flash module (To protect up to 16GB memory per controller)
USB LCM (optional)
2 x hot pluggable/redundant fan modules
Operating temperature : 0 to 40°C
Shipping temperature : -10°C to 50°C
Operating relative humidity : 20% to 80% non-condensing
Non-operating relative humidity : 10% to 90%
System : 3 years
Battery backup module : 1 year ; Super capacitor module : 1 year
