Name: Supermicro Mainstream A+ Server AS-2015A-TR - 2U UP Mainstream with up to 8 hot-swap 3.5" SAS/SATA bays and 1 PCIe 5.0 slot + 1 PCIe 4.0 slot
Brand: Supermicro
SKU: UK-SUP-AS-2015A-TR
Availability: OutOfStock

Supermicro Mainstream A+ Server AS-2015A-TR - 2U UP Mainstream with up to 8 hot-swap 3.5" SAS/SATA bays and 1 PCIe 5.0 slot + 1 PCIe 4.0 slot

Product code: UK-SUP-AS-2015A-TR

Condition: New

Availability: Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.uk | Call Us: +44 330 043 2524

Request A Quote

Description
Warranty Information
Shipping Policy
Protection Plans

Description

Supermicro Mainstream A+ Server AS-2015A-TR - 2U UP Mainstream with up to 8 hot-swap 3.5" SAS/SATA bays and 1 PCIe 5.0 slot + 1 PCIe 4.0 slot

Key Applications

Designed for financial companies
AMD Xilinx Solarflare X2 and X3 Ethernet adapters validated

Key Features

AMD EPYC 4004 / 4005 or Ryzen 7000 / 9000 series LGA1718 up to 170W TDP Processors
4 DDR5-5200 UDIMM ECC/Non-ECC slots supporting up to 192GB memory
2 PCIe 5.0 x16 HHHL slots (16/NA or 8/8)
IPMI 2.0 + KVM with Dedicated LAN (1GbE)
Dual 1GbE LAN (Intel I210-AT)
800W High-Efficiency Power Supply Titanium Level Certified

Specifications

Product SKUs
A+ Server AS -2015A-TR

Motherboard
Super H13SAE-MF

Processor
CPU	Single processor(s) AMD EPYC 4004 / 4005 or AMD Ryzen 7000 / 9000 Series Processors
Core Count	Up to 16C/32T
Note	Supports 60W - 170W TDP CPUs (Air Cooled)

GPU
Max GPU Count	Up to 1 double-width or 2 single-width GPUs
Supported GPU	NVIDIA PCIe: RTX A2000, L4 View GPU Options
CPU-GPU Interconnect	PCIe 5.0 x16 CPU-to-GPU Interconnect

System Memory
Memory	Slot Count: 4 DIMM slots Max Memory (2DPC): Up to 192GB 5200MT/s ECC/non-ECC DDR5 UDIMM View Memory Options
Memory Voltage	1.1V

On-Board Devices
SATA	SATA (6Gbps) ; RAID 0/1 support
NVMe	NVMe; RAID 0/1 support(Native)
Chipset	AMD B650
Network Connectivity	1 RJ45 1GbE with Realtek RTL8211F PHY (dedicated IPMI) 2 RJ45 1GbE with Intel® I210-AT View AOC Options

Input / Output
LAN	1 RJ45 1 GbE Dedicated BMC LAN port
USB	3 Type-A ports(Rear) 2 Type-C ports(Rear) 1 Type-C port(Rear)
Video	1 VGA port 1 DisplayPort 1.4 port 1 HDMI 2 port
Audio	Rear Audio
TPM	1 TPM header

System BIOS
BIOS Type	AMI 32MB SPI Flash

Management
Software	SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New!
Power configurations	ACPI 6.0 Power Management

Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Supply Chain Security: Remote Attestation Runtime BMC Protections

PC Health Monitoring
FAN	Status monitor for speed control
Voltage	+1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM
Other Features	8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor
Temperature	CPU thermal trip support, Monitoring for CPU and chassis environment, PECI

Chassis
Form Factor	2U
Model	CSE-825TQC-R802LPB

Dimensions and Weight
Height	3.5" (89 mm)
Width	17.2" (437 mm)
Depth	25.5" (647 mm)
Package	11.4" (H) x 26.7" (W) x 34.5" (D)
Weight	Gross Weight: 52 lbs (23.59 kg) Net Weight: 37 lbs (16.78 kg)
Available Color	Black

Front Panel
LED	HDD activity LED Network Activity LEDs Power Fail LED Power status LED System Information LED
Buttons	Power On/Off button System Reset button

Expansion Slots
PCI-Express (PCIe) Configuration	Default 1 PCIe 4.0 x4 LP slot 2 PCIe 5.0 x16 LP slots View AOC Options

Drive Bays / Storage
Drive Bays Configuration	Default: Total 8 bays 8 front hot-swap 3.5" SAS/SATA drive bays View Drive Options
M.2	2 M.2 PCIe 5.0 x4 NVMe slots (M-key 2280/22110) View M.2 Options

System Cooling
Fans	3x 80mm Fan(s)
Air Shroud	1 Air Shroud

Power Supply

2x 800W Redundant (1 + 1) Titanium Level (96%) power supplies

Dimension (WxHxL)	76 x 40 x 336 mm
Input	800W: 100-240Vac / 50-60Hz 800W: 200-240Vdc / 50-60Hz
+12V	Max: 66A / Min: 0A (100Vac-240Vac) Max: 66A / Min: 0A (200Vdc-240Vdc)
5V SB	Max: 4A / Min: 0A
Output Type	Backplanes (gold finger)

Operating Environment
Environmental Spec.	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
