Tangent Medix M24T 24” Medical Computer, UL60601-Certified, 2 x 260-pin DDR4, 2x SO-DIMM up to 64GB, All-in-One Medical Computers

Product code: UK-TAN-Medix M24T
Condition: New
Availability: Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.uk | Call Us: +44 330 043 2524

Request A Quote

SSL Secure Payment

Tangent Medix M24T 24” Medical Computer, UL60601-Certified, 2 x 260-pin DDR4, 2x SO-DIMM up to 64GB, All-in-One Medical Computers

Tangent Medix M24T 24” Medical Computer, UL60601-Certified, 2 x 260-pin DDR4, 2x SO-DIMM up to 64GB, All-in-One Medical Computers

Tangent Medix M24T 24” Medical Computer, UL60601-Certified, 2 x 260-pin DDR4, 2x SO-DIMM up to 64GB, All-in-One Medical Computers

Features
• 24” Cleanable / PCAP Touch Screen
• Intel 10th Gen. Core i7/i5 Processors
• 2 x 260-pin DDR4 SO-DIMM, up to 64GB
• High Performance NVMe storage
• Antimicrobial Enclosure
• Fanless Construction w/Heat Pipes
• TPM 2.0 (fTPM)
• Optional UPS Battery Backup
• Optional vPro
• Optional Single Sign-on RFID (Integrated)

Medical Computer Features

Medix M24T 24” Medical Computer features the Intel Core Series, 2 x 260-pin DDR4, 2x SO-DIMM up to 64GB, high performance storage, UPS battery backup, IP65 front & IPX2 back panels, antimicrobial enclosure, fanless design, TPM, vPro and RFID.

Intel 10th Gen Core i5/i7

Fast and responsive, ready for performance and multi-tasking.

IP54 Front | IPX2 Back

Can be sprayed and wiped clean without damaging the internals.

Antimicrobial

Factory treated with an antimicrobial additive to battle surface contamination.

UPS Battery Backup

Up to 30 minutes of standby power.

UL60601-Certified, All-in-One Medical Computers

Tangent Medical Grade Computers designed for healthcare.

UL60601-Certified

UL60601 Certification ensures essential performance and safe-use around other medical electrical equipment.

IP Rating

Sealed and Protected from water and dust intrusion. Easy to spray and wipe clean, aiding in contaminant protection

Antimicrobial

Extra period after environments.

Mission Critical Medical Grade Computers for Healthcare

Medical grade computers or medical PCs are specifically designed for healthcare environments. To safeguard clinicians and for patient safety, a medical PC must be UL/IEC60601-1 certified to be considered medical grade. IEC 60601-1 Certification is granted when a medical electrical device undergoes testing for safety and performance compliance. Certification helps to guarantee reliability and ensure the medical device won't cause harm to staff or patients. 60601-1 certified medical grade PCs offered by Tangent have passed rigorous standards to obtain this certification.

Tangent is a leading provider of cutting-edge medical computers designed for the healthcare industry. 15-inch to 24-inch all-in-one medical grade computers designed for arm mounting, wall mounting, medical stations, or cart installations can be used in a variety of healthcare environments. No matter where you need a mission critical computer, you can find the ideal medical grade all-in-one computer in Tangent’s product line for healthcare.

Tangent's medical grade computers are designed with antimicrobial enclosures. The antimicrobial agent in our medical computers is a necessary component of computers specifically manufactured to address patient and medical staff safety. Antimicrobial medical grade computers help to prevent hazardous surface contamination and promote infection control.

Medical Computer Features to Benefit the Healthcare Industry

Additional features vary by Medical PC model, and can include:

Ingress protection and can be sprayed and wiped clean without damaging the internal components of the computer.
Battery operation- Tangent is the first computer manufacturer to introduce a medical grade computer operated by hot-swappable batteries to the healthcare industry. This feature is poised to serve the unique need of the healthcare industry for medical cart device integration.
Tangent medical grade computers are backed by knowledgeable, talented US-based Technical Support and up to 3-year product warranties. Our medical computers are fully-customizable for healthcare application needs.

SPECIFICATIONS

Display
LCD Size 23.8” (16:9)
Max. Resolution 1920 x 1080 (FHD)
Touch
Touch Screen Projected Capacitive w/10 points
System
Processor Intel 10th Gen. Core i5/i7 Processors – 35 Watt (Comet Lake)
System Chipset Intel H470 (Comet Lake)
Graphics Controller Intel HD Graphic 630 (Core CPU)
LAN Chipset 1 x GbE: Intel I219-V
1 x GbE: Realtek RTL8111
Audio Realtek ALC283
System Memory Up to 64GB DDR4 2133/2400 (2 x SO-DIMM)
BIOS Insyde 64Mbit
TPM TPM 2.0 (fTPM)
vPro Yes(Optional)
Storage
M.2 NVMe 1 x Up to 2TB NVMe M.2 2280 “M” Key (PCIe x 4)
Expansion
M.2 1 x M.2 (M Key) supports M.2 2280
1 x M.2 (E Key) support M.2 2230
Other Features
Cooling Method Fanless w/ Heat Pipes
Internal Speaker 2 x 1W speakers
WebCam 1 x 5Mpixel Camera (Optional)
I/O
Video 1x HDMI
COM 3x DB9 Serial RS232
USB 4x USB 3.0 (Rear)
2 x USB 2.0 (rear)
LAN 2 x GbE RJ45
WLAN 802.11 AX + BT 5.1 LE (Intel WiFi AX200)
Audio 1 x Line-out
Others 1 x Power Switch
4 x Function Buttons
1 x SSO RFID (Optional)
1 x Keystroke RFID (Optional)
2 x Built-in Microphones
Operating System
Windows Windows 10 Pro 64bit (UEFI Only)
Windows 10 IoT SAC/LTSC 64bit (UEFI Only)
Windows 11 Pro
Windows 11 IoT SAC
Power
Power Input Voltage 19 VDC
Power Connector Barrel Plug
Battery 1 x Li-ion UPS Backup Only (Optional) 24W – 11.1V @2100 mah
Power Adapter External Power Adapter, 19V @6.31A
Environment
Operating Temp. 32°F to 104°F (0°C to 40°C)
Storage Temp. -4°F to 140°F (-20°C to 60°C)
Relative Humidity 10% to 90% non-condensing
IP Level IP65 front
IPX2 back
Certification CE
EN 55011: 2009+A1: 2010 Class B
EN 60601-1: 2006
IEC 60601-1-6: 2010/AMDI:2013,
1807005-CB
EN-60601-1-2: 2-15
EN-61000-3-2: 2014
EN-61000-3-3: 2013, UL/CUL 60601-1
FCC
EnergyStar 8.0
Physical
Enclosure Materials ABS + PC Plastics Emclosure, Antimicrobial Enclosure
Dimension (WxHxD) 22.3" x 14.6" x 1.8"
(567/0mm x 370.5mm x 45.2mm)
Weight Without base: 13.1 lbs. (5.95 kg)
With base: 17.6 lbs. (8 kg)
Mounting VESA 100, Optional Stand
Warranty
Warranty 1-Year Standard
