Product Specification
| Form Factor | 3.5-inch | |
|---|---|---|
| Buffer Size | 512 MiB | |
| Rotation Speed | 7200 rpm | |
| Data Transfer Speed ( Sustained ) | 262 MiB/s | |
| Power Consumption ( Idle - A ) | SATA | 4.00 W |
| SAS | 4.46 W | |
| MTTF | 2 500 000 h | |
| Weight ( Max ) | 720 g | |
Key Features
- Industry Standard 3.5-inch 26.1 mm Height Form Factor
- Conventional Magnetic Recording (CMR) 16TB for broad compatibility
- Industry-leading 9-disk helium-sealed design for superior storage density
- 7,200 rpm Performance
- 550 Total TB Transferred per Year Workload Rating
- 512e or 4Kn Advanced Format Sector Technology; (512e Model) Includes Toshiba Persistent Write Cache Technology for Data-Loss Protection in Sudden Power-Loss Events
- Self-Encripting Drive(SED) option model available
Applications
- Cloud-scale Sever and Storage Infrastructure
- Software-defined data center infrastructure
- File- and Object-based storage infrastructure
- Tiered Storage Infrastructure
- Workloads and Use-Cases that Benefit from High Capacity per Spindle
- Capacity-Optimized Cloud-scale and Rack-Scale Storage Systems
- Compliance Data Life-Cycle Management
- Data Center Data-Protection and Data Back-up Infrastructure
Lineup
| Capacity | Interface | Format | Type | Model Number |
|---|---|---|---|---|
| 16 TB | SATA | 4Kn | Standard | MG08ACA16TA |
| 16 TB | SATA | 4Kn | SED | MG08ACP16TA |
| 16 TB | SATA | 512e | Standard | MG08ACA16TE |
| 16 TB | SATA | 512e | SED | MG08ACP16TE |
| 16 TB | SAS | 4Kn | Standard | MG08SCA16TA |
| 16 TB | SAS | 4Kn | SED | MG08SCP16TA |
| 16 TB | SAS | 512e | Standard | MG08SCA16TE |
| 16 TB | SAS | 512e | SED | MG08SCP16TE |
- Source of Industry-leading : Toshiba Electronic Devices & Storage Corporation, as of January, 2019 for the 3.5-inch, 26.1mm height.
- Product image may represent a design model.
- Definition of capacity: Toshiba defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the definition of 1GB = 230 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media files) will vary based on file size, formatting, settings, software and operating system, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
- A kibibyte (KiB) means 210, or 1,024 bytes, a mebibyte (MiB) means 220, or 1,048,576 bytes, and a gibibyte (GiB) means 230, or 1,073,741,824 bytes.
- MTTF (Mean Time to Failure) is not a guarantee or estimate of product life; it is a statistical value related to mean failure rates for a large number of products which may not accurately reflect actual operation. Actual operating life of the product may be different from the MTTF.
- Read and write speed may vary depending on the host device, read and write conditions, and file size.
- SED: Self-Encrypting Drive
- "3.5-inch" mean the form factor of HDDs. They do not indicate drive's physical size.
- Workload is a measure of the data throughput of the year, and it is defined as the amount of data written, read or verified by commands from the host system.
