The NexStar JX, USB 3.2 Gen1x1, 3.5" or 2.5” SATA III HDD/SSD Drive Green Enclosure with eSATA is a redesigned enclosure for easy removal of the drive. It features a hard aluminum case that effectively draws away the heat to keep your hard drive running at optimal temperature. This NexStar JX comes with smart and green features to extend the life of the drive by spinning down when the system goes to sleep thus saving energy when it is not in use. The latest UASP protocol and SATA III 6Gbps support faster transfer and backup of files. We at Vantec USA, built this NexStar JX series to continue the same tradition of the legacy NexStar 3 series that is designed to last and grow with you.
- Design For Large Capacity Drive
- Support 3.5” or 2.5” SATA III HDD/SSD Drive
- SATA III specification max 6Gbps (Backwards Compatible With SATA II/I)
- Adopt UASP to Enhance Maximum Performance of Hard Drive for Windows 10/11
- Aluminum Casing Cools Down Your Hard Drive
- Vents To Exhaust Hot Air To Let In Cool Air
- Maximum Transfer Rates Up to 5 Gbps w/USB 3.2 Gen1x1
- Maximum Transfer Rates Upto 6 Gbps for eSATA
- Easily Add Storage to Any System/Appliance with USB or eSATA
- Hi-Quality Shielded USB and eSATA Cable Ensures Data Integrity and Speed
- Hot-Swappable: Plug & Play Without Rebooting for USB and eSATA (with system support)
- No Drivers Needed (NDN) for Windows OS and OSX
evice Support: SATA III/II/I Hard Drive or SSD
Device Size: 3.5” or 2.5” Standard SATA Drive
Internal Interface: Standard SATA III
External Interface: USB 3.0 Type-B and eSATA
Interface Cable: USB Type-B to Type-A and eSATA cable
USB/eSATA Cable Length: Each 39 inches / 1000 mm
HDD Capacity: Up to 20TB* via USB; 20TB via eSATA*
Material: Aluminum casing, ABS Plastic
Autoswitching Ac Adapter: 12V, 2A, Cable Length: 45 inches / 1143 mm
Dimensions (without Stand): 7.87 x 4.76 x 1.34 inches / 200 x 121 x 34 mm
Dimensions (with Stand): 7.87 x 5.04 x 2.32 inches / 200 x 128 x 59 mm
Item Weight (Enclosure + Stand): 14.3 oz. / 406g
OS Support: Windows 11, 10, 8.1, 8, 7; OS X 10.6, or greater; Linux
*Check www.Vantec usa.com FAQ for the latest current capacity. Make sure your eSATA port can support the capacity.
Environmental:
Operating Temperature: 0 ℃ to +45℃
Operating Humidity: 10% to 85 % RH (no condensation)
Storage Temperature: -10℃ to +70℃
Storage Humidity: 5% to 90% RH (no condensation)
System Requirements:
- OS with USB storage support or eSATA support
- USB 3.0 Type-A port or eSATA port
Package Contents:
- 1 x NexStar JX, 3.5" SATA III Hard Drive Enclosure
- 1 x Ac Adapter; 1 x Screw Set; 1 x USB cable; 1 x eSATA cable
- 1 x Enclosure Stand; 1 x Quick Install Guide
UPC: 844767023694
EAN: 4716872103911
Country of Origin: Taiwan
