Product Description
AMD is now offering its second generation Pb-Free (RoHS compliant) USB compatible cable for in-circuit configuration and programming of all AMD devices.
The Platform Cable USB II provides integrated firmware to deliver high-performance, reliable and user-friendly configuration of AMD FPGAs and programming of AMD PROM and CPLD devices. The Platform Cable USB II cable optimizes direct programming of third-party SPI flash memory devices and indirect programming of SPI or parallel NOR flash memory devices via the FPGA JTAG port. In addition, Platform Cable USB II is a cost effective tool for debugging embedded software and firmware when used with AMD applications such as the Embedded Development Kit and ChipScope™ Pro Analyzer.
Platform Cable USB II is an upgrade to and backwards compatible with Platform Cable USB. It has industry-leading performance and is compatible with Full Speed (USB 1.1) and Hi-Speed (USB 2.0) ports.
| Comparison Metric | Platform Cable USB II | SmartLynq Data Cable |
|---|---|---|
| Device Programming and Hardware Debug | Y | Y |
| Basic Software Debug | Y | Y |
| OS / Hypervisor Aware Debug | N | Y |
| Remote Access/Debug Capability | N | Y |
| USB 2.0 Host Interface | Y | Y |
| 10/100/1000 Ethernet Host Interface | N | Y |
| Default Bitstream Programming Speed (MB/s) | 0.4 | 4 |
| JTAG Max Clock Speed (MHz) | 12 | 40 |
| Connection to Target via PC4 JTAG or Flying Leads (provided) | Y | Y |
| GPIO Available with Flying Leads Cable (provided) | N | Y |
| Hardware Server Application | On Host | Local to Cable |
