StarTech.com 8.3ft (2.5m) 1-Port FTDI USB to Serial RS232 Adapter Cable with Optical Isolation, USB to RS232 Adapter - TAA. Connector 1: DB-9, Connector 2: USB A, Cable length: 2.5 m. Product colour: Black
Add an RS232 serial port with circuit isolation to your laptop or desktop computer, through USB
The ICUSB2321FIS 1-Port FTDI USB to Serial RS232 Adapter Cable with Optical Isolation converts an available USB 1.1 or 2.0 port into an RS232 DB9 port that can be used to connect, monitor and control your serial devices. The USB to serial adapter features integrated optical isolation circuits and surge protection to protect your critical, sensitive control equipment against electrical damage, making it a viable solution for costly industrial serial devices. The versatile FTDI chipset also supports COM retention, additional customization/features, and compatibility not offered by most other solutions. Broad operating system compatibility including Windows®, Windows CE, Mac OS and Linux, makes this product easy to integrate into mixed environments. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Specifications
| General | |
|---|---|
| Brand | StarTech.com |
| Manufacturer part number | ICUSB2321FIS |
| HSSL part number | UK-STT-ICUSB2321FIS |
| UPC / GTIN | 0065030845373 |
| Product type | Cable Gender Changers |
| Ports & interfaces | |
| Connector 1 | DB-9 |
| Connector 2 | USB A |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Cable length | 2.5 m |
| Performance | |
| Product colour | Black |
| Housing material | Plastic |
| USB required | Yes |
| Chipset | FTDI - FT232RL |
| Data bits | 7, 8 |
| Stop bits | 1, 2 |
| Baud rate | 921.6 Kbit/s |
| Parity bit | Even, Mark, No, Odd, Space |
| Isolation | 2500 kV |
| FIFO (First In, First Out) | 256 B |
| Compatible operating systems | Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11 Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, 13.0 Linux Kernel 3.0.x+ |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Relative humidity | 5 - 95% |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Certification | CE, FCC, Microsoft WHQL |
| Sustainability | |
| Sustainability compliance | Yes |
| Weight & dimensions | |
| Width | 40 mm |
| Depth | 2400 mm |
| Height | 20 mm |
| Weight | 86 g |
| Packaging content | |
| Manual | Yes |
| Drivers included | Yes |
| Other features | |
| Gross weight (imperial) | 0.2 kg (0.44 lbs) |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number UK-STT-ICUSB2321FIS.
