StarTech.com 1 Port PCI RS232 Serial Adapter Card with 16550 UART. Host interface: PCI, Output interface: Serial, Serial interface type: RS-232. Certification: CE, FCC, RoSH. Chipset: NetMos NM9820CV. Windows operating systems supported: Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64,..., Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012. Width: 20 mm, Depth: 120 mm, Height: 120 mm
Add an RS-232 serial port to your PC through a PCI expansion slot
The PCI1S550 16550 Serial PCI Card can be installed in a PCI slot to add one RS232 serial port - a cost-effective solution for connecting any new serial device or old legacy serial device, with data transfer rates of up to 115.2 Kbps.
Perfect for connecting serial modems, POS devices, PDAs, digital cameras, printers, ISDN terminal adapters and more, to your system, the 1 serial port PCI card supports IRQ sharing and operates flawlessly in Windows, DOS and Linux platforms.
A convenient easy to install solution, the PCI serial card can be connected in minutes through simple plug and play installation and is backed by a StarTech.com lifetime warranty and free lifetime technical support.
The StarTech.com Advantage
- Compatible with any PC running Windows, DOS or Linux for simple integration into your application - Data transfer rates of up to 115.2 Kbps for efficient serial device performance - Easy to install and use with full step-by-step instruction providing a hassle free serial solution
Specifications
| General | |
|---|---|
| Brand | StarTech.com |
| Manufacturer part number | PCI1S550 |
| HSSL part number | UK-STT-PCI1S550 |
| UPC / GTIN | 0065030785396 |
| Product type | Interface Cards/Adapters |
| Ports & interfaces | |
| Host interface | PCI |
| Output interface | Serial |
| Serial ports quantity | 1 |
| Serial interface type | RS-232 |
| Design | |
| Internal | Yes |
| Certification | CE, FCC, RoSH |
| Features | |
| Chipset | NetMos NM9820CV |
| Plug and Play | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 80 °C |
| Storage temperature (T-T) | -20 - 100 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| System requirements | |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 95, Windows 98SE, Windows ME, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012 |
| Technical details | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 20 mm |
| Depth | 120 mm |
| Height | 120 mm |
| Other features | |
| Data transfer rate | 0.920 Mbit/s |
| I/O ports | 1 - DB9 M |
| Connectivity technology | Wired |
| Mac compatibility | Yes |
| Compatible operating systems | DOS, Windows 95/ 98SE/ 2000/ XP(32/64bit)/ Server 2003(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Linux, & Mac OS 10.4.x & Windows XP Embedded/ POS Ready 2009/ Embedded System 2009 OS |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number UK-STT-PCI1S550.
