StarTech.com 4 Port USB DVI KVM Switch with DDM Fast Switching Technology and Cables. Keyboard port type: USB, Mouse port type: USB, Video port type: DVI-I. Maximum resolution: 1920 x 1200 pixels, Maximum digital resolution: 1920 x 1200 pixels, Number of users: 1 user(s). Product colour: Black, Housing material: Steel, Certification: CE, FCC, TAA, UL, REACH. Input voltage: 100 - 240 V, Input current: 0.4 A, Output voltage: 5 V. Compliance certificates: RoHS
Control 4 DVI, USB-equipped PCs with a single peripheral set, with USB Dynamic Device Mapping to avoid switching lag-time
The SV431DVIUDDM 4-Port USB DVI KVM Switch lets you control 4 DVI, USB-equipped PCs using a single peripheral set at high-definition DVI resolutions up to 1920x1200.
The included KVM cables provide a ready-out-of-the-box solution, while USB Dynamic Device Mapping (DDM) and Display Data Channel (DDC) features work to significantly reduce switching lag-time and improve overall compatibility with your connected display and input devices, saving you time and money.
For the next level in KVM performance, this DVI KVM switch integrates dual-core dedicated processing per channel and innovative, USB DDM technology that enables you to quickly switch between connected computers with next-to-zero delay. DDM maintains a constant communication channel between your USB peripherals and connected systems, avoiding the time necessary for your systems to re-recognize the devices when switching.
In addition to faster switching, the KVM offers All-time Display Data Channel (Full DDC) technology to maintain proper display detection among connected systems, a simple one-touch button for hot-key selection and an integrated 2-port USB hub allowing you to share additional peripherals.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Switch between devices with minimal lag through fast-switching DDM technology - Instant setup and operation with included KVM cables - Near universal compatibility with all USB input devices through USB DDM Ports
Specifications
| General | |
|---|---|
| Brand | StarTech.com |
| Manufacturer part number | SV431DVIUDDM |
| HSSL part number | UK-STT-SV431DVIUDDM |
| UPC / GTIN | 0065030858199 |
| Product type | KVM Switches |
| Ports & interfaces | |
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| Console ports | DVI-I, USB A |
| Console USB ports quantity | 2 |
| USB hub | Yes |
| USB 2.0 ports quantity | 2 |
| USB 2.0 Type-A hub ports quantity | 2 |
| Audio connections | No |
| DC-in jack | Yes |
| Network | |
| Ethernet LAN | Yes |
| Performance | |
| Maximum resolution | 1920 x 1200 pixels |
| Maximum digital resolution | 1920 x 1200 pixels |
| Daisy chain | No |
| Number of users | 1 user(s) |
| Design | |
| Rack mounting | No |
| Product colour | Black |
| Housing material | Steel |
| LED indicators | Yes |
| Hot keys | Yes |
| Certification | CE, FCC, TAA, UL, REACH |
| Display | |
| Built-in display | No |
| Power | |
| Input voltage | 100 - 240 V |
| Input current | 0.4 A |
| Output voltage | 5 V |
| Output current | 2 A |
| Power consumption (typical) | 10 W |
| External power adapter | Yes |
| Power plug type | Type M |
| Compatible power plug types | EU, UK, US |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 138 mm |
| Depth | 66 mm |
| Height | 22 mm |
| Weight | 1.1 kg |
| Packaging content | |
| Cables included | KVM |
| Manual | Yes |
| AC adapter included | Yes |
| Other features | |
| Audio support | Yes |
| IP control | No |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number UK-STT-SV431DVIUDDM.
Additional information
Startech 4 Port USB DVI KVM Switch with DDM Fast Switching Technology and Cables - Control 4 DVI, USB-equipped PCs with a single peripheral set, with USB Dynamic Device Mapping to avoid switching lag-time - 4 Port USB DVI KVM Switch with DDM Fast Switching Technology - Four Port DVI USB KVM Switch - DDM KVM Switch - Cables Included
The SV431DVIUDDM 4-Port USB DVI KVM Switch lets you control 4DVI, USB-equipped PCs using a single peripheral set at high-definition DVI resolutions up to 1920x1200.
The included KVM cables provide a ready-out-of-the-box solution, USB Dynamic Device Mapping (DDM) works to reduce switching lag-time, and Display Data Channel (DDC) improves overall compatibility with your connected display and input devices.
For the next level in KVM performance, this DVI KVM switch integrates dual-core dedicated processing per channel and innovative, USB DDM technology that enables you to quickly switch between connected computers with next-to-zero delay. DDM maintains a constant communication channel between your USB peripherals and connected systems, avoiding the time necessary for your systems to re-recognize the devices when switching.
In addition to faster switching, the KVM offers All-time Display Data Channel (Full DDC) technology to maintain proper display detection among connected systems, a simple one-touch button for hot-key selection and an integrated 2-port USB hub allowing you to share additional peripherals.
Backed by a Startech 2-year warranty and free lifetime technical support.
More from the Manufacturer
- USB DDM technology and Dual-Core design for lag-free switching
- Supports HD resolutions up to 1920x1200
- Supports DDC copy and emulation to all ports
- Includes four 6ft KVM Cables (USB/DVI)
- Integrated 2-port USB 2.0 hub
- One-touch selectable Hot-keys and front panel push-button computer selection
- No drivers or software required
