Broadcom Integrated BroadR-Reach Multilayer Switch for Industrial Networking - BCM54501
The Broadcom BCM54501 device is Broadcom's first fully integrated BroadR-Reach multilayer switch to support industrial networking applications. The BCM54501 is the optimal solution for key industrial designs that have high performance yet challenging low-power requirements. Built upon industry-leading 65-nm architecture, the BCM54501 supports multiple intuitive low-power modes as well as cable diagnostics features. The BCM54501 can interconnect with other devices for scalable, high-performance systems through multiple interfaces, including RGMII, SGMII, GMII, MII, and reverse MII.
The BCM54501 supports four integrated BroadR-Reach PHYs, one integrated BroadR-Reach/100TX PHY, and two uplink ports. The BCM54501 is available in a 176-pin LQFP package and is qualified for industrial temperature range (–40°C to +85°C).
The BCM54501 supports four integrated BroadR-Reach PHYs, one integrated BroadR-Reach/100TX PHY, and two uplink ports. The BCM54501 is available in a 176-pin LQFP package and is qualified for industrial temperature range (–40°C to +85°C).
Features
Interfaces:
- Four dedicated BroadR-Reach PHY single-pair interfaces
- One dual-mode BroadR-Reach single-pair or 10/100 two-pair interface
- One RGMII/GMII/MII/RvMII/TMII/RvTMII with IMP management capability
- One RGMII/MII/RvMII/TMII/RvTMII/SerDes/SGMII interface supports direct connect to SFP
- One internal GMII interface to an ARM subsystem
- Programming interfaces
- SPI flash
- SPI registers access
- MDIO
- EEPROM
- GPIO (PWM/interrupt/level)
- Serial LEDs
- Time synchronization interface
- 1.2V core voltage, 3.3V I/O voltage, 2.5V RGMII JTAG
Package:
- 176-pin LQFP
Switch core:
- Seven-port full-line-rate performance (64 jumbo frames) Frame priority based on IEEE 802.1p, receive port, or IPv4/IPv6 TOS
- Four data queues, plus two AV queues per port (can be used for general purposes): – Four general-purpose and two AV-dedicated classof-service (CoS) levels – Strict priority and WRR scheduling among the four general-purpose CoS levels – Shaping (leaky bucket) for AVB queues (configurable for AVB or Standard mode)
- Port-based VLAN assignment Up to 4,096 VLANs
- MAC-based link aggregation with automatic, hardwarebased link failover
- Port-based rate control
- Port-based ingress and egress mirroring
- Compact field processor (CFP) 128-rule multiple classifier
- AV bridging (IEEE 802.1AS) with hardware support and IEEE 802.1Qav
- DoS attack prevention
- IGMP/MLS snooping
- Rapid spanning tree
- Multiple spanning tree (up to eight instances)
- Nonspanning-tree loop detection
- Double tagging/Q-in-Q Egress VID remarking
- IEEE 802.3x programmable per-port full-duplex flow control and half-duplex backpressure
- IEEE 802.1x port-based authentication
- 4K-entry MAC address table with hardware- or software-based learning and aging
- 128 KB packet buffer (1 KB = 1024 bytes)
- Cable plant diagnostics
- Power Savings modes – Deep Sleep mode – Ultralow Power mode
- Jumbo frame support up to 9,720 bytes
Processor subsystem:
- ARM Cortex-R4 processor core
- 32K internal ROM
- 92K TCM SRAM memory
- 512K system SRAM memory
- Random number generator
- SPI flash interface
- 40K DMA buffer
- JTAG debugging
- Default configuration load from external flash
- Power-saving clocking modes: reference-clock, fullrate, and half-rate operation
- Processor core clock frequency: 250 MHz
- System bus clock frequency: 125 MHz
- Broadcom Serial Control Interface
Time processing unit:
- IEEE 1588 Transparent Clock (both end-to-end and peer-to-peer) 1-Step processing
- IEEE Audio Video Broadcast (AVB) protocol stack (IEEE 802.1AS Bridge Clock/BMCA and IEEE 802.1Qat SRP) Broadcom
Applications
- Industrial Automation
- Smart Grid
- Video Surveillance
- Elevator and Escalator Controls
- Building Control
- Inflight Entertainment
- In-Train Communication
