Broadcom Quad Low-Power Unidirectional 10 GbE Referenceless CDR/EyeOpener - BCM8324
Fully integrated multirate CDR with EyeOpener, limiting amplifier and loss-of-signal detection, operating from 8.5 Gb/s to 11.4 Gb/s.
The BCM8324 is ideal for applications in 40-GbE modules and 4x 10G applications, and for retiming 10G signals on line cards for SFI/XFI compliance. The BCM8324 provides high-jitter tolerance and low-jitter generation and is designed to comply with Optical Internetworking Forum (OIF), IEEE 802.3ae, Telcordia, ANSI and ITU-T jitter standards. The BCM8324 can be powered with a single 1.0V supply without any special power supply sequencing requirements. The BCM8324 is available in an 8 mm x 8 mm, 81-pin BGA.
Features
- Programmable Tx pre-emphasis
- Programmable Rx Eq
- Low latency <1ns
- Optional reference clock
- Fully integrated multirate quad CDR
- Rates from 8.5 Gb/s to 11.4 Gb/s
- Integrated limiting amplifier
