Broadcom Single-port RGMII 10/100/1000BASE-T PHY with EEE & WOL - BCM54210E

Description
Warranty Information
Shipping Policy

Description

Broadcom Single-port RGMII 10/100/1000BASE-T PHY with EEE & WOL - BCM54210E

The Broadcom BCM54210E is a triple-speed 1000BASE-T/100BASE-TX/10BASE-T Gigabit Ethernet (GbE) transceiver integrated into a single monolithic CMOS chip. The device performs all physical-layer functions for 1000BASE-T, 100BASETX, and 10BASE-T Ethernet on standard category 5 UTP cable. 10BASE-T can also run on standard category 3, 4, and 5 UTP. The BCM54210E is a highly integrated solution combining digital adaptive equalizers, ADCs, phase-locked loops, line drivers, encoders, decoders, echo cancellers, crosstalk cancellers, and all required support circuitry. Based on Broadcom’s proven digital signal processor technology, the BCM54210E is designed to be fully compliant with RGMII, allowing compatibility with industry-standard Ethernet MACs and switch controllers. Designed for reliable operation over worst-case category 5 cable, the BCM54210E automatically negotiates with its link partner to determine the highest possible operating speed. The device detects and corrects most common wiring problems. The BCM54210E features CableChecker diagnostics, which detects common cable problems including shorts, opens, and cable length.

Features

Single-chip integrated triple-speed Ethernet transceiver
1000BASE-T IEEE 802.3ab
100BASE-TX IEEE 802.3u
10BASE-T IEEE 802.3
100BASE-EFX
Supports RGMII MAC interface
Supports SOFT-RESET
Ethernet@Wirespeed
Integrated voltage regulator
Trace matched output impedance
Line-side loopback
Low EMI emissions
Cable plant diagnostics
Robust Cable-sourced Electrostatic Discharge (CESD) tolerance
Support for jumbo packets up to 10 KB
Detection and correction of pair swaps
(MDI crossover), pair skew, and pair polarity
Advanced power management
IEEE 1149.1 (JTAG) boundary scan
Super-isolate mode
Wake-on-LAN (WOL)
IEEE 802.3az-compliant support
Support for native Energy Efficient Ethernet (EEE) MACs
Support for legacy non-EEE MAC using AutogrEEEn mode
AutogrEEEn+
48-pin QFN package

Applications

GbE switches and uplinks
Management Port
Industrial Automation
Customer Premise Equipment (CPE)
Video Surveillance
LED Controller
