The Cisco UCS® C480 ML M5 Rack Server is a no-compromise purpose-built Cisco UCS C-Series server for deep learning in a 4-Rack-Unit (4RU) form factor.
The Cisco UCS C480 ML M5 Rack Server is a purpose-built server for deep learning. It is storage- and I/O-optimized to deliver industry-leading performance for training models. The Cisco UCS C480 ML M5 delivers outstanding levels of storage expandability and performance options for standalone or Cisco Unified Computing System&trade (Cisco UCS)&ndashmanaged environments in a 4RU form factor. And because of its modular design you pay for only what you need. It offers these capabilities:
- Eight NVIDIA SXM2 V100 32G modules with NVLink interconnect
- The latest Intel® Xeon® Scalable processors with up to 28 cores per socket and support for two processor configurations. It supports both first- and second-generation Intel Xeon Scalable CPUs
- 2933-MHz DDR4 memory and 24 DIMM slots for up to 7.5 terabytes (TB) of total memory
- Support for the Intel Optane&trade DC Persistent Memory (128G 256G and 512G)
- Memory speeds increase from 2666 MHz to 2933 MHz
- Intel Optane DC Persistent Memory Modules (DCPMM) &ndash 128G 256G and 512G[1]
- Up to 7.5 TB using 12x128G DDR4 DIMMs and 12x512G Intel Optane DC Persistent Memory Modules
- Four PCI Express (PCIe) 3.0 slots for 100G UCS VIC 1495
- Flexible storage options with support for up to 24 Small-Form-Factor (SFF) 2.5-inch SAS/SATA Solid-State Disks (SSDs) and Hard-Disk Drives (HDDs)
- Up to six PCIe NVMe disk drives
- One Cisco® 12-Gbps SAS Modular RAID Controller in a dedicated slot
- M.2 boot options
- Dual embedded 10 Gigabit Ethernet LAN-On-Motherboard (LOM) ports
Table 1 summarizes the features and benefits of the Cisco UCS C480 ML M5.
| Feature | Benefit |
| Eight NVIDIA SXM2 V100 32GB modules with NVLink interconnect | Fast deep learning model training |
| Modular storage support with up to 24 front-accessible hot-swappable Hard Disk Drives (HDDs) and Solid-State Disks (SSDs) | Modularity to right-size storage options to match training requirements Flexibility to expand as storage needs increase |
| High-capacity memory support of up to 3 TB using 128-GB DIMMs and up to 7.5 TB using Intel Optane DC Persistent Memory Modules | Large memory footprint to deliver performance and capacity for large-model training |
| Up to six PCIe NVMe drives | Up to six Gen3 x4 lanes NVMe drives for extreme I/O performance for faster model training |
| Support for up to four PCIe Generation 3.0 slots | Support for up to four 10/25G or 40/100G Cisco VICs |
| Hot-swappable redundant power supplies | Increased high availability |
| Integrated dual 10-Gbps Ethernet | Increased network I/O performance and additional network options |
Compute and I/O optimized for industry-leading performance
The Cisco UCS C480 ML M5 is a purpose-built enterprise-class rack server for deep learning that is compute- and I/O-optimized to deliver industry-leading performance for faster model training irrespective of training data size.
The Cisco UCS C480 ML M5 can be managed with Cisco Intersight&trade. Cisco Intersight is a new cloud-based management platform that uses analytics to deliver proactive automation and support. By combining intelligence with automated actions you can reduce costs dramatically and resolve issues more quickly.
The C480 ML M5 servers can be deployed as standalone servers or in a Cisco UCS&ndashmanaged environment. When used in combination with Cisco UCS Manager the C480 ML M5 brings the power and automation of unified computing to enterprise applications including Cisco SingleConnect technology drastically reducing switching and cabling requirements. Cisco UCS Manager uses service profiles templates and policy-based management to enable rapid deployment and help ensure deployment consistency. It also enables end-to-end server visibility management and control in both virtualized and bare-metal environments. The Cisco Integrated Management Controller (IMC) delivers comprehensive out-of-band server management with support for many industry standards including:
- Redfish Version 1.01 (v1.01)
- Intelligent Platform Management Interface (IPMI) v2.0
- Simple Network Management Protocol (SNMP) v2 and v3
- Syslog
- Simple Mail Transfer Protocol (SMTP)
- HTML5 GUI
- HTML5 virtual Keyboard-Video-Mouse (vKVM)
- Command-Line Interface (CLI)
- XML API
Management Software Development Kits (SDKs) and DevOps integrations exist for Python Microsoft PowerShell Ansible Puppet Chef and more. For more information about integrations see Cisco DevNet.
| Product | Specifications |
| Form factor | 4RU rack server |
| Processors | Intel Xeon Scalable CPUs (2) or second-generation Intel Xeon Scalable CPUs (2) |
| Memory | 24 DDR4 DIMM slots: 16 32 64 and 128 GB up to 2933 MHz Support for the Intel Optane DC Persistent Memory (128G 256G and 512G) |
| PCIe slots | Four PCIe 3.0 slots |
| RAID controllers | Internal controllers: ● Cisco 12-Gbps Modular RAID Controller (PCIe 3.0) with 4-GB Flash-Backed Write Cache (FBWC) providing enterprise-class data protection for up to 24 SAS/SATA HDDs and SSDs |
| Internal storage | Support for up to 24 hot-swappable 2.5-inch Small-Form-Factor (SFF) drives with up to six PCIe NVMe drives: DVD drive option |
| Embedded Network Interface Cards (NICs) | Dual 10GBASE-T Intel x550 Ethernet ports |
| Power supplies | Hot-pluggable redundant 1600W AC |
| Other storage | Dual M.2 SATA SSD drives for installing an operating system or hypervisor |
| Management | ● Cisco Intersight ● Cisco Integrated Management Controller ● Cisco UCS Manager |
| Rack options | Cisco ball-bearing rail kit with optional reversible cable management arm |
| Hardware and software interoperability | See the Cisco Hardware and Software Interoperability List for a complete listing of supported operating systems and peripheral options |
