The CyberPower ABP36VRM2U rack/tower convertible Extended Battery Module (EBM), which extends battery runtimes during power outages, is designed for Smart App Online UPS systems OL1000RMXL2U and OL1500RMXL2U. This EBM takes 2U of rack space and can be installed to rack or tower configuration to match the UPS form factor. Up to four EBMs can be added to the UPS, and the module's DC plug-and-play power connectors allow for daisy-chaining EBMs to a UPS system. The ABP36VRM2U typically has a UPS charging time of three hours. For estimated runtimes, see the Estimated Runtimes table. The ABP36VRM2U comes with a three-year warranty.
Technical specifications
| Battery Quantity | 6 |
|---|---|
| Battery Size | 12 V / 7 Ah |
| Battery Type | Sealed Lead-Acid Battery |
| Battery — Replacement Battery Cartridge | YUASA – NP7-12 |
| Battery — Typical Recharge Time | 3 Hours (0% to 90% charged) |
| Battery — User Replaceable Battery | Yes |
| Output — USB Charge Port | No |
| Physical — Rack Height | 2U |
| Dimensions — Physical Dimensions – (WxHxD) (cm) | 43.82 x 8.89 x 49.53 (cm) |
| Dimensions — Physical Dimensions – (WxHxD) (in) | 17.25 x 3.5 x 19.5 (in) |
| Dimensions — Physical Dimensions – (WxHxD) (mm) | 438 x 89 x 495 (mm) |
| Warranty — Product Warranty | 3 Year Limited Warranty |
Documentation
CyberPower ABP36VRM2U product page, specifications and downloads — published by CyberPower Systems.
Support and procurement
Supplied with the manufacturer's standard warranty. HSSL Technologies can quote this unit on its own or as part of a wider power protection and rack build, including replacement battery packs, management cards and installation.
Specifications are provided by CyberPower Systems and are subject to change. Images may not be exact — please confirm the exact configuration on your quotation.
