The CyberPower Smart App Online OL6KRT2UTFTAA rack/tower step-down isolation transformer converts 208V input voltage originating from utility power, a UPS, or a generator to 120V output. A 6-foot cord, with a 30A NEMA L6-30P plug, connects the OL6KRTUTF to input power. Over temperature protection safeguards your OL6KRT2UTFTAA from damage if the internal heat exceeds safe operating parameters.The OL6KRT2UTFTAA has a capacity of 5,000VA / 5,000Watts at 120V. It features twelve NEMA 5-20R receptacles that can support output to NEMA 5-15P and 5-20P plugs. A three-year warranty backs the OL6KRT2UTFTAA.
Technical specifications
| General — Over Temperature Protection | Yes |
|---|---|
| Input — Cord Length | 6 ft (1.8 m) |
| Input Frequency Range | 50 Hz – 60 Hz |
| Input Plug Type | NEMA L6-30P |
| Input Voltage Range | 200 VAC – 240 VAC |
| Input — Maximum Input Current | 30A (Derated to 24A) |
| Input — Nominal Input Voltage | 208 VAC |
| Output — Nominal Output Voltage | 120 VAC |
| Output — Outlet Type | 12 – NEMA 5-20R |
| Output — Outlets – Total | 12 |
| Output Frequency | 50/60 Hz (auto-sensing/configurable) |
| Output — Overload Protection | 20A Output Circuit Breakers X 4 |
| Output — USB Charge Port | No |
| Output — VA | 5000 VA |
| Output — Watts | 5000 W |
| Physical — Form Factor | Rack / Tower |
| Physical — Material of Construction | Metal |
| Physical — Mounting Hardware | Yes |
| Physical — Rack Height | 2U |
| Dimensions — Physical Dimensions – (WxHxD) (cm) | 43.18 x 8.89 x 66.04 (cm) |
| Dimensions — Physical Dimensions – (WxHxD) (in) | 17 x 3.5 x 26 (in) |
| Dimensions — Physical Dimensions – (WxHxD) (mm) | 432 x 89 x 660 (mm) |
| Dimensions — Physical Weight (kg) | 58.2 |
| Dimensions — Physical Weight (lb) | 128.3 |
| Dimensions – Shipping — Shipping – Weight (kg) | 77.56 |
| Dimensions – Shipping — Shipping – Weight (lb) | 171 |
Documentation
CyberPower OL6KRT2UTFTAA product page, specifications and downloads — published by CyberPower Systems.
Support and procurement
Supplied with the manufacturer's standard warranty. HSSL Technologies can quote this unit on its own or as part of a wider power protection and rack build, including replacement battery packs, management cards and installation.
Specifications are provided by CyberPower Systems and are subject to change. Images may not be exact — please confirm the exact configuration on your quotation.
