The CyberPower PDU20SW8FNET, an 8-outlet (front), 1U rackmount switched power distribution unit (PDU), provides 120V 20A output. It distributes power to 8 NEMA 5-20R receptacles from a single NEMA 5-20P plug with unfiltered electrical pass-through. The switched outlet receptacles can be managed individually or collectively over the network, using the CyberPower Management Console, a web browser, and the RJ45 Ethernet port for network connection, or locally by using the LCD controls.
Technical specifications
| Input — Cord Length | 12 ft (3.7 m) |
|---|---|
| Input Frequency Range | 50 Hz – 60 Hz |
| Input Plug Type | NEMA 5-20P |
| Input — Maximum Input Current | 20A |
| Input — Plug Style | Straight |
| Output — Meter Readout | Kilowatts Voltage Amperage IP Address |
| Output — Nominal Output Voltage | 100 – 120 VAC |
| Output — Outlet Banks | 1 |
| Output — Outlet Type | 8 – NEMA 5-20R |
| Output — Outlets – Front | 8 |
| Output — Outlets – Rear | 0 |
| Output — Outlets – Total | 8 |
| Output — Overload Protection | None |
| Output — USB Charge Port | No |
| Management & Communications — Hardware Connection Port | RJ45 Serial |
| Management & Communications — LED Indicators | Load Tx/Rx LINK Outlets |
| Management & Communications — SNMP / HTTP Remote Monitoring | TCP/IP, UDP, DHCP, SNMP, HTTP |
| Physical — Adjustable Mounting Brackets | 2 sets (L-Short, L-Long) |
| Physical — Color | Black |
| Physical — Cord Retention Tray/Cord Organizers | Yes |
| Physical — External Site Ground Pin | Yes |
| Physical — Form Factors Supported | 1U Rackmount 0U Vertical Rackmount Undercounter Installation Supported |
| Physical — Material of Construction | Metal |
| Physical — Rack Height | 1U |
| Physical — Style | Rackmount Vertical Rackmount Under-Counter |
| Dimensions — Physical Dimensions – (WxHxD) (cm) | 43.31 x 4.45 x 11.2 (cm) |
Documentation
CyberPower PDU20SW8FNET product page, specifications and downloads — published by CyberPower Systems.
Support and procurement
Supplied with the manufacturer's standard warranty. HSSL Technologies can quote this unit on its own or as part of a wider power protection and rack build, including replacement battery packs, management cards and installation.
Specifications are provided by CyberPower Systems and are subject to change. Images may not be exact — please confirm the exact configuration on your quotation.
