• 300 Mbps 802.11n speed
• 2*3 dBi external antennas boost signal to extend WiFi coverage up to 200㎡
• One button extension help to extend WiFi coverage easily
• Smart WiFi Signal Strength LED help to choose optimum location easily
• Compatible with main brands 802.11n standard wireless routers and WiFi DSL
• Support SSID Hiding

Specification

General

• Product Dimension (W × H × D): 111mm×56mm×47.7mm
• Package Dimension (W × H × D): 148mm×98mm×72mm
• Net Weight: 0.221 kg
• Packing List:

WiFi Extender× 1

Quick Start Guide × 1

Regulatory Compliance and Safety Information × 1

• Packing Method: Single pack
• Working Temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity: 10% to 90% RH non-condensing
• Storage Temperature: -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
• Storage Humidity: 10% to 90% RH non-condensing
• Max. Power Consumption: ≤ 3.8 W
• Gross Weight: 0.192 kg

Wireless Parameter

• Data Rate:

≤ 300 Mbps

2.4 GHz: 300 Mbps

• Wireless Standard: IEEE802.11b,IEEE 802.11g, IEEE 802.11n @2.4GHz
• Working Frequency Band: 2.4 GHz
• Transmitting Power: <20dBm
• Wireless Performance: 2*2 MIMO supported
• Receiving Sensitivity:

2.4 GHz

11b-1M:-96dBm

11g-54M:-77dBm

11n-20M-MCS7:-75dBm

11n-40M-MCS7:-73dBm

• Antenna: 2*3dBi external antennas

Hardware Parameter

• LED Indicator: 1 * Signal/Power/WPS LED
• Reset

1 * WPS Button

1 * Reset Button

• Power Supply Method: 100-240V ~50/60HZ 0.3A

Software Function

• Application function: Repeater Mode
• Security Mode:

Default encryption mode: Mix WPA-PSK/WPA2-PSK

WPA algorithm: TKIP

• Security Mechanism: Hide SSID
• Management Method: Web
• Upgrade: Web
• System Log: Firmware upgrade, Restore factory settings, Login password, and Reboot
