The 690R is a high-performance fiber optic receiver for SDI video signals up to 3G HD-SDI. The 690T converts two 3G HD-SDI signals to single-mode fiber optic and the 690R receiver converts them back to the two original SDI formats. Compatible with the fiber optic matrix VS-88FO.
- Primary Information
Device Type: Receiver Form Factor: External Data Transfer Rate: 3 Gbps Connectivity Technology: Wired Interfaces: Dual single?mode fiber (9/125) over LC connectors Max Transfer Distance: 6.21 Mil(s) - Networking
Data Link Protocol: 2 Gigabit Ethernet - Dimensions&Miscellaneous
Width: 2.44 Inch Depth: 2.03 Inch Height: 0.96 Inch - Special Feature
COO: ISRAEL - UNSPSC Code
UNSPSC Code: 43222608
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +44 330 043 2524 | You can also use the quote request page
