NetApp AFF A1K. Flagship modular AFF for the largest mission-critical and AI workloads; up to 40M IOPS and 1TB/s per cluster.
AFF A1K systems are configured to order - capacity, drives, networking, ONTAP software and support are chosen for your deployment. Tell us your capacity, performance and protocol needs and we will return a configured quote.
Specifications
| Family | NetApp AFF |
|---|---|
| Model | AFF A1K |
| Max scale out | 2-24 nodes (12 HA pairs) |
| Max ssds | 2880 |
| Capacity effective | up to 330PB (5:1 efficiency, max SSDs) |
| Rack units | 2x 2U controller modules + NS224 shelves (no internal drives) |
| Power median | 2,718W (with NS224) |
| PCIe slots per ha pair | 18 |
| Host ports | 200GbE/100GbE/25GbE, 64Gb FC |
| OS | ONTAP 9.15.1+ |
| Shelves | NS224 (2U, 24 NVMe SFF) |
| Drive types | NVMe TLC SSD |
| Protocols | FC, iSCSI, NVMe/FC, NVMe/TCP, NFS, NFSv4/RDMA, SMB, S3 |
| Controllers | active-active HA pair |
| Performance family | up to 40M IOPS / 1TB/s per cluster (A1K); latency as low as 100 microseconds |
| Manufacturer part number | AFF A1K |
Specifications are from NetApp's published datasheet; configured systems vary.
